Airtac APX Y-Type Tee Fitting APX10-02
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Joint APX10-02 Technical Specifications
- Model: APX10-02
- Type: Y-shaped pneumatic tee connector (equal distribution)
- Thread standard: Metric (M5 × 0.8) & BSPP options
- Port configuration: 3-way (1 inlet / 2 outlets)
- Material: Brass body with chrome plating
- Seal material: NBR (Nitrile) rubber
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Operating temperature: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 24g ±0.5g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra0.2μm (internal flow path)
- Leakage rate: <0.1 mL/min under 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered Y-connector featuring symmetrical flow channels for balanced pressure distribution in compact pneumatic systems. The electroless nickel plating ensures corrosion resistance in humid environments, while the tapered thread design prevents air leakage during high-frequency vibrations.
- Branch line connections in automated assembly robots
- Dual-actuator synchronization circuits
- Modular pneumatic test benches
- Medical device gas delivery systems
- Packaging machine air distribution nodes
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 1.2-1.5 N·m torque using backup wrench.
Avoid axial misalignment exceeding 3°. For vertical mounting, orient flow arrow upward.
- APX series push-to-connect fittings (4mm/6mm/8mm tubing)
- ASL10-02 flow control valves
- AST10 series tube sleeves
| Property | Property Value |
|---|---|
| sku | APX10-02 |
