Airtac APX Y-Type Tee Fitting APX10-03
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX10-03 Technical Details
- Model: APX10-03 (ISO 15407-1 compliant)
- Type: Equal-diameter Y-shaped pneumatic tee
- Port configuration: 3-way female threaded ports
- Thread standard: M5×0.8 metric thread (BSPP/NPT optional)
- Material: Nickel-plated brass body
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (continuous) / 120℃ peak
- Flow coefficient (Cv): 0.32
- Weight: 28g ±1g (including packaging)
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H) (body only)
- Branch angle: 120° ±2° (Y-division geometry)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Certifications: RoHS compliant, REACH SVHC-free
Precision-engineered Y-connector featuring balanced flow distribution with ±3% flow deviation between branches. The 120° angled design minimizes turbulent flow and pressure drop (ΔP < 0.02MPa at 0.5MPa input). Includes anti-vibration thread locking features and chemical-resistant seals suitable for compressed air, inert gases, and mild hydraulic fluids.
- Industrial automation: Pneumatic circuit branching in robotic EOAT systems
- Medical equipment: Gas line distribution in dental chairs/imaging machines
- Transportation: Air brake system tees in commercial vehicles
- Energy: Solar thermal system manifold connections
Mounting guidance:
Apply 2-3Nm torque during installation. Use thread sealant only on male ports.
Align flow arrow (marked on body) with primary flow direction. Maximum
vibration tolerance: 5G @ 10-2000Hz.
- Works with Ø4mm/Ø6mm polyurethane tubing (push-in type)
- Recommended for use with AirTAC GR series regulators
- Compatible with ISO 15407-1 standard fittings
| Property | Property Value |
|---|---|
| sku | APX10-03 |
