Airtac APX Y-Type Tee Fitting APX10-M10
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX10-M10 Technical Details
- Model: APX10-M10 (Y-Type Branching Fitting)
- Thread standard: Metric (M)
- Port size: M10×1.0 (triple ports identical)
- Material: Nickel-plated brass (base), NBR seals
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 48g ±2g
- Dimensions: 32mm (L) × 28mm (W) × 28mm (H)
- Flow coefficient (Cv): 0.45
- Surface treatment: Electrolytic polishing anti-oxidation
- Leakage rate: ≤0.1 NL/min under 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection class: IP40 (dust protected)
Precision-engineered Y-shaped pneumatic connector with equal-diameter branching, featuring triple M10 ports arranged at 120° angles. The nickel-brass construction ensures corrosion resistance in humid environments while maintaining 98% flow efficiency. Includes pre-installed thread seal rings for leak-free installation.
- Pneumatic circuit branching in CNC machine tool manifolds
- Air distribution networks for packaging line actuators
- Modular pneumatic system prototyping
- Compressed air monitoring setups (pressure gauge teeing)
- Robotic arm end-effector air supply splitting
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using backup wrench on hex flats.
Avoid overtightening which may deform NBR seals.
Perform pressure test at 1.25× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | APX10-M10 |
