Airtac APX Y-Type Tee Fitting APX10-M12
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APX10-M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Copper-free construction ensures direct applicability in copper-restricted environments;
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
Installation protocol:
Apply 2-3 drops of pneumatic sealant (viscosity ≤35 cSt) on threads before assembly.
Tighten to 12-15 N·m torque using crowfoot wrench. Avoid overtightening beyond 18 N·m
to prevent thread deformation. Perform pressure test at 1.25× working pressure after installation.
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX10-M12 Technical Details
- Model: APX10-M12 (Standard Y-Type)
- Thread specification: M12×1.0 (ISO 1179-1 compliant)
- Material: Nickel-plated brass body
- Seal type: Dual NBR O-rings (ISO 6149 compliant)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Flow capacity: 750 NL/min @0.5 MPa
- Port configuration: 3-way equal diameter
- Surface treatment: Electroless nickel plating (8-12μm)
- Weight: 38±2 grams
- Dimensions: 34mm (L) × 34mm (W) × 26mm (H)
- Thread engagement depth: 10.5mm (minimum)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined Y-connector with 120° branch angle for optimized flow distribution. Features anti-vibration thread design with dual sealing layers, compatible with pneumatic and low-viscosity hydraulic systems (ISO 32 grade or below). Meets ISO 14000 environmental standards.
Typical Implementation Scenarios:
- Robotic end-effector pneumatic circuits
- CNC machine tool lubrication line distribution
- Packaging machine air jet control systems
- Semiconductor wafer handling vacuum/pressure switching
- Electric vehicle battery cooling system manifolds
Installation protocol:
Apply 2-3 drops of pneumatic sealant (viscosity ≤35 cSt) on threads before assembly.
Tighten to 12-15 N·m torque using crowfoot wrench. Avoid overtightening beyond 18 N·m
to prevent thread deformation. Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APX10-M12 |
