Airtac APX Y-Type Tee Fitting APX10-M16
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APX10-M16
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Copper-free construction ensures direct applicability in copper-restricted environments;
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
Installation protocol:
Apply thread sealant (Loctite 577 recommended) to male threads before assembly.
Tighten to 25-30 N·m torque using a crowfoot wrench. Avoid overtightening -
maximum allowable rotation after seal contact is 1.5 turns.
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX10-M16 Technical Details
- Model: APX10-M16
- Type: Y-shaped triple port pneumatic connector
- Thread standard: Metric (M16×2.0)
- Material: Brass with nickel-plated surface
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) O-rings
- Leakage rate: ≤0.1 NL/min under rated pressure
- Proof pressure: 1.5 MPa (217.5 psi)
- Surface hardness: HV200-250
- Weight: 82g ±2g
- Dimensions: 46mm (L) × 36mm (W) × 28mm (H)
- Port configuration: 1 input (M16) + 2 outputs (M16)
- Corrosion resistance: 96hrs salt spray test passed
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined Y-connector with optimized flow channels, featuring 25% lower pressure drop compared to standard tees. The 60° branch angle ensures balanced flow distribution, while the hexagon base allows tool-assisted tightening. Compatible with ISO 1179-2 standard fittings.
Typical Applications:
- Pneumatic circuit branching in automation equipment
- Air supply distribution for multi-cylinder systems
- Modular pneumatic manifold assemblies
- Compressed air instrumentation networks
- Robotic end-effector air line splitting
Installation protocol:
Apply thread sealant (Loctite 577 recommended) to male threads before assembly.
Tighten to 25-30 N·m torque using a crowfoot wrench. Avoid overtightening -
maximum allowable rotation after seal contact is 1.5 turns.
| Property | Property Value |
|---|---|
| sku | APX10-M16 |
