Airtac APX Y-Type Tee Fitting APX12-01
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX12-01 Technical Specifications
- Model: APX12-01
- Type: Y-shaped three-way connector (equal distribution)
- Material: Nickel-plated brass (standard) / Stainless steel optional
- Thread standard: PT1/8 (BSPP) / NPT1/8 available on request
- Operating pressure: 0.05–1.5 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃ (NBR seals) / -20℃ to 150℃ (FKM seals optional)
- Surface treatment: Electroless nickel plating (3-5μm thickness)
- Weight: 28±2g
- Dimensions: 21.5mm (L) × 19.8mm (W) × 25.4mm (H)
- Flow coefficient (Cv): 0.45
- Leakage rate: <0.1 mL/min under 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered Y-branch pneumatic connector featuring low-pressure loss design with internal flow channel optimization. The 120° angled ports ensure balanced flow distribution, while the hexagon body design allows tool-assisted tightening. Compatible with ISO 1179-2 standards for industrial interoperability.
- Pneumatic circuit splitting in robotic end effectors
- Modular manifold systems for semiconductor equipment
- Medical device gas line distribution
- Simultaneous actuator control in assembly lines
- Vacuum system pressure balancing networks
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (for BSPP). Tighten to 8-10 N·m torque maximum.
Avoid cross-threading during manifold block installation. Compatible with Ø6mm and Ø8mm tubing
when used with corresponding sleeves (sold separately).
| Property | Property Value |
|---|---|
| sku | APX12-01 |
