Airtac APX Y-Type Tee Fitting APX12-M12
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX12-M12 Technical Details
- Model: APX12-M12
- Type: Y-shaped pneumatic tee connector
- Material: Brass with nickel plating (stainless steel variant available)
- Thread specification: M12×1.0 external thread (ISO 6149 standard)
- Operating pressure: 0-1.0 MPa (145 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile O-rings)
- Surface treatment: Electroless nickel plating (3-5μm thickness)
- Leakage rate: <0.1 NL/min under rated pressure
- Protection rating: IP40
- Certifications: RoHS compliant, CE marked
- Weight: 28g ±0.5g
- Dimensions: 30mm (L) × 20mm (W) × 20mm (H)
Precision-machined Y-connector featuring triple-port configuration (1 inlet/2 outlets) with 60° branch angle design. The hexagonal body allows tool-assisted installation while the corrosion-resistant coating ensures durability in humid environments. Compatible with φ12mm OD pneumatic tubing via push-to-connect installation (tube insertion depth: 18mm).
- Pneumatic circuit branching in automation lines
- Air supply distribution for multi-axis actuators
- Modular pneumatic system prototyping
- Compressed air splitting in packaging machinery
- Medical gas line distribution systems
- Educational pneumatic training kits
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 12-15 N·m torque using 17mm wrench.
Ensure tube ends are square-cut and deburred before insertion. Maximum lateral load: 5N.
| Property | Property Value |
|---|---|
| sku | APX12-M12 |
