Airtac APX Y-Type Tee Fitting APX12-M16
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX12-M16 Technical Details
- Model: APX12-M16
- Type: Y-shaped triple union (equal tee)
- Material: Brass with nickel plating / Stainless steel 304 (optional)
- Thread standard: Metric fine thread (M16×1.5)
- Port configuration: Three M16 female threads at 120° angles
- Max working pressure: 1.0 MPa (10 bar)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Operating temperature: -5℃ to +80℃
- Seal material: NBR (Nitrile rubber) standard / FKM (Viton®) optional
- Surface roughness: Ra ≤3.2μm
- Weight: 120±5g (brass version)
- Dimensions: 30mm (center-to-port length) × 30mm (port diameter) × 35mm (vertical height)
- Protection rating: IP40 (dust protected)
- Compliance: RoHS 2.0 compliant
Precision-machined Y-connector featuring triple M16 ports arranged in 120° geometry for balanced flow distribution. The hydrodynamic internal channel design reduces turbulence by 30% compared to standard tees. Electroless nickel plating provides corrosion resistance (200hrs salt spray test passed). Compatible with air, water, and inert gases.
- Pneumatic system branch line distribution
- Coolant line splitting in CNC machinery
- Vacuum system manifold connections
- Hydraulic test bench configurations
- Packaging machine air circuit networks
- Automotive assembly line tooling systems
Installation guidelines:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 25-30 N·m torque using crowfoot wrench.
Avoid overtightening which may deform sealing surfaces.
For vertical installation, orient flow arrow upward.
| Property | Property Value |
|---|---|
| sku | APX12-M16 |
