Airtac APX Y-Type Tee Fitting APX12-M20
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX12-M20 Technical Details
- Model: APX12-M20
- Series: APX Standard Series
- Thread specification: M20×1.5 (ISO 228-1 G3/4 compatible)
- Material: Aluminum alloy ADC12 (anodized surface)
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Flow coefficient (Cv): 2.8
- Weight: 52g ±2g
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
- Port configuration: 1 inlet (M20) + 2 outlets (M20)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: ≤10Hz/1.5mm amplitude
- Protection rating: IP40 (dust protected)
Precision-machined Y-shaped pneumatic connector featuring 120° branch angle for optimized flow distribution. The tapered thread design ensures leak-proof connections in high-vibration environments. Compatible with ISO 15407-1 standards, with corrosion-resistant anodization for humid environments.
- Pneumatic circuit branching in automated production lines
- Air tool manifold systems
- Packaging machinery air distribution networks
- Industrial robot end-effector pneumatic controls
- Compressed air monitoring systems
Installation protocol:
Apply 3-5 wraps of PTFE tape on male threads (do not over-tighten beyond 35N·m torque).
For vertical installations, position outlet ports downward to prevent moisture accumulation.
Perform pressure test at 1.5× operating pressure after assembly.
| Property | Property Value |
|---|---|
| sku | APX12-M20 |
