Airtac APX Y-Type Tee Fitting APX16-03
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX16-03 Technical Details
- Model: APX16-03
- Type: Y-shaped pneumatic tee connector (equal distribution)
- Thread standard: PT1/8 (BSPP) female threads on all ports
- Material: Aerospace-grade aluminum alloy (A6063-T5)
- Surface treatment: Hard anodized (25μm thickness)
- Operating pressure: 0.05-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile) rubber (optional FKM available)
- Flow coefficient (Cv): 0.45
- Weight: 28g ±1g
- Dimensions: 22mm (L) × 16mm (W) × 16mm (H)
- Port angles: 120° between branch ports
- Vibration resistance: 10-2000Hz (IEC 60068-2-6)
- Corrosion resistance: 96hrs salt spray test passed
Precision-machined Y-connector featuring triple-port flow division with minimal pressure drop (ΔP < 0.02MPa @ 0.5MPa). The 120° angled design optimizes space utilization in compact pneumatic systems while maintaining laminar flow characteristics. Anodized surface ensures scratch resistance and chemical compatibility with industrial lubricants.
- Multi-axis pneumatic tool synchronization
- Robotic end-effector air distribution
- CNC machine tool clamping circuits
- Food packaging line actuator networks
- Semiconductor cleanroom equipment
Installation guidelines:
Apply thread sealant (LOCTITE 5452 recommended) on male threads only.
Maximum tightening torque: 1.5N·m. Avoid axial stress on ports -
use flexible tubing within 150mm of connection points.
| Property | Property Value |
|---|---|
| sku | APX16-03 |
