Airtac APX Y-Type Tee Fitting APX16-M20
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX16-M20 Technical Details
- Model: APX16-M20 (Y-Type)
- Thread standard: Metric (M)
- Port configuration: 1 input / 2 output (equal distribution)
- Male thread size: M20×1.5 (external)
- Female thread size: M16×1.5 (internal)
- Material: Lead-free brass CW617N
- Surface treatment: Electro-nickel plated (8-12μm)
- Pressure rating: 0.2-1.5 MPa (29-217 PSI)
- Burst pressure: ≥3.0 MPa
- Operating temperature: -20℃ to 120℃
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Weight: 182±5g
- Dimensions: 60mm (L) × 30mm (W) × 45mm (H)
- Flow coefficient (Cv): 4.2
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered Y-shaped pneumatic connector featuring dual sealing surfaces and anti-vibration grooves. The asymmetrical port design allows compact installation in confined spaces while maintaining optimal flow characteristics. Compatible with ISO 1179-1 and DIN 3852 standards for universal fitting.
- Pneumatic circuit branching in CNC machine tools
- Air distribution in automated assembly lines
- Modular piping systems for semiconductor equipment
- Simultaneous actuator control in packaging machinery
- Compressed air networks with space constraints
Installation protocol:
Apply 20-25 N·m torque during assembly using proper thread sealant.
Align flow arrows with system direction. Pressure test at 1.8 MPa
for 3 minutes post-installation. Replace O-rings every 5,000 operating hours.
| Property | Property Value |
|---|---|
| sku | APX16-M20 |
