Airtac APX Y-Type Tee Fitting APX4-02
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX4-02 Technical Details
- Model: APX4-02
- Type: Y-shaped triple port tee connector
- Material: Brass with nickel plating (stainless steel optional)
- Thread standard: PT1/8 (BSPP) / NPT1/8 optional
- Port configuration: 1 inlet / 2 outlets (equal flow division)
- Max working pressure: 1.0 MPa
- Pressure rating: 0.2-0.8 MPa (recommended operating range)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (HNBR/FKM available for special orders)
- Surface treatment: Electrolytic polishing
- Weight: 14.7g ±0.5g
- Dimensions: 19.5mm(L) × 16mm(W) × 19.5mm(H)
- Flow coefficient (Cv): 0.12
- Vibration resistance: ≤10Hz @ 1.5mm amplitude
Precision-engineered Y-divider for pneumatic systems, featuring optimized flow channels to minimize pressure drop (ΔP ≤0.02MPa @ 0.5MPa). The 60° branch angle ensures balanced flow distribution while maintaining compact dimensions. Corrosion-resistant construction with IP54-equivalent sealing performance.
- Pneumatic circuit branching in robotic end effectors
- Dual-cylinder synchronization systems
- Modular pneumatic manifolds for packaging machinery
- Air supply distribution in semiconductor handling equipment
- Medical device pneumatic control units
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 12-15N·m torque.
For vertical mounting, orient Y-axis horizontally to prevent condensate pooling.
Use with 5μm filtered dry air (pressure dew point ≤3℃).
| Property | Property Value |
|---|---|
| sku | APX4-02 |
