Airtac APX Y-Type Tee Fitting APX4-M10
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APX4-M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Copper-free construction ensures direct applicability in copper-restricted environments;
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
Installation protocol:
Apply thread sealant only on male threads (not required for BSPP).
Tighten to 12-15 N·m torque using crowfoot wrench.
Avoid overtightening - maximum 1.5 rotations past finger-tight.
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX4-M10 Technical Details
- Model: APX4-M10
- Type: Y-shaped triple port tee connector
- Material: Nickel-plated brass (stainless steel variant available)
- Thread specification: M10 × 1.0 (ISO metric fine thread)
- Port configuration: 1 input / 2 output (equal distribution)
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: HNBR (hydrogenated nitrile) with PTFE backup ring
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Flow coefficient (Cv): 0.45
- Weight: 52g ±2g
- Dimensions: 32mm (L) × 24mm (W) × 24mm (H)
- Compliance: RoHS 2.0 compliant, REACH SVHC-free
Precision-machined Y-connector featuring 60° branch angle for optimized flow distribution. The hexagonal body design allows tool tightening (17mm wrench flat) while the recessed o-ring groove prevents seal extrusion. Rated for 500,000+ cycles with proper installation.
Common Applications:
- Pneumatic circuit splitting in multi-axis robots
- Modular assembly of SMC manifold systems
- Dual-actuator control in packaging machinery
- Air supply distribution for CNC tool changers
- Vacuum system branching in electronic component handling
Installation protocol:
Apply thread sealant only on male threads (not required for BSPP).
Tighten to 12-15 N·m torque using crowfoot wrench.
Avoid overtightening - maximum 1.5 rotations past finger-tight.
Media Compatibility:
- Compressed air (lubricated or non-lubricated)
- Inert gases (N₂, CO₂)
- Not recommended for: Steam, corrosive gases, or petroleum-based fluids
| Property | Property Value |
|---|---|
| sku | APX4-M10 |
