Airtac APX Y-Type Tee Fitting APX4-M12
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APX4-M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Copper-free construction ensures direct applicability in copper-restricted environments;
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using crowfoot wrench.
Avoid thread compound contamination in flow paths.
Perform pressure test at 0.8 MPa after installation.
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Connector APX4-M12 Technical Details
- Model: APX4-M12
- Type: Y-shaped triple port connector (equal distribution)
- Thread specification: M12×1.25 (all ports female)
- Material: Nickel-plated brass (standard), SS304 optional
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (standard), FKM available for chemical resistance
- Surface hardness: HV300±20 (nickel plating)
- Proof pressure: 1.5 MPa
- Leakage rate: ≤0.1 NL/min @ 0.5 MPa
- Weight: 48±2g
- Dimensions: 30mm (L) × 25mm (W) × 25mm (H)
- Port angles: 120°±1° between branches
- Surface treatment: Electroless nickel plating (8-12μm)
Precision-machined pneumatic tee connector with optimized flow channels for minimal pressure drop (ΔP ≤ 0.02 MPa @ 0.5 MPa). Features self-aligning threads and triple O-ring groove design for vibration-resistant sealing. Compatible with ISO 15407-1 standard pneumatic systems.
Common Implementations:
- Robotic arm pneumatic circuit branching
- Packaging machine air distribution manifolds
- Simultaneous tool actuation in assembly lines
- Compressed air sampling systems
- Modular pneumatic test benches
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using crowfoot wrench.
Avoid thread compound contamination in flow paths.
Perform pressure test at 0.8 MPa after installation.
| Property | Property Value |
|---|---|
| sku | APX4-M12 |
