Airtac APX Y-Type Tee Fitting APX4-M6
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Series Y-Type Tee Fitting APX4-M6 Technical Details
- Model: APX4-M6
- Type: Y-shaped triple port pneumatic connector
- Thread specification: M6×1 (ISO metric fine thread)
- Material: Brass with nickel-plated surface
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0.2-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Port configuration: Three M6 female threads (120° Y-pattern)
- Surface roughness: Ra ≤1.6μm
- Weight: 5.2±0.3g
- Dimensions: 20mm (Body length) × 18mm (Port-to-port width) × 16mm (Height)
- Torque specification: 1.2-1.5 N·m installation torque
- Compliance: RoHS 2.0 compliant
Precision-engineered Y-connector featuring optimized flow channels with 18% lower pressure drop than standard tees. The electroplated brass construction resists corrosion in humid environments while maintaining 500,000+ cycle durability. Features dual-stage sealing with integrated O-ring groove design.
- Pneumatic circuit branching in robotic gripper systems
- Air pressure distribution in CNC machine tool changers
- Modular pneumatic manifold assemblies
- Medical device gas line connections
- Laboratory instrument air distribution networks
Installation protocol:
Apply 1.5 wraps of PTFE tape on male threads (ASME B1.20.1 standard).
Use calibrated torque wrench for installation. Maximum angular
misalignment tolerance: ±2°. Avoid cross-threading during multiple
reconnections.
| Property | Property Value |
|---|---|
| sku | APX4-M6 |
