Airtac APX Y-Type Tee Fitting APX6-01
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Fitting APX6-01 Technical Details
- Model: APX6-01
- Type: Y-shaped triple port connector (equal distribution)
- Thread specification: G1/8 (ISO228 standard)
- Material: Anodized aluminum alloy 6063-T5
- Surface treatment: Chromate conversion coating
- Max working pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Seal type: Dual O-ring design (NBR 70±5 Shore A)
- Flow coefficient (Cv): 0.15
- Weight: 28±2g
- Dimensions: 32mm (L) × 24mm (W) × 24mm (H)
- Port angles: 120° between branch ports
- Vibration resistance: 10-2000Hz, 20m/s² max
- Certification: RoHS compliant
Precision-machined Y-connector featuring symmetrical flow paths for balanced pressure distribution. The 45° angled entry ports minimize turbulence, while the dual-seal design prevents cross-port leakage even under pulsating pressures. Compatible with pneumatic and low-viscosity fluid systems.
- Pneumatic cylinder synchronization circuits
- Modular assembly in factory automation lines
- Medical gas distribution manifolds
- Robotic end-effector tool switching systems
- Energy-saving air preparation units
Installation guidance:
Apply thread sealant only on male threads (not required for port seals).
Tighten to 1.2-1.5 N·m torque using a crowfoot wrench. Avoid overtightening
which may deform O-ring grooves. Compatible with tubing OD 6mm.
| Property | Property Value |
|---|---|
| sku | APX6-01 |
