Airtac APY Y-Type Tee Fitting APY8
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APY8
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Copper-free design ensures safe operation in environments where copper materials are prohibited;
2. Comprehensive model range with multiple specifications accommodates diverse pneumatic system requirements;
3. Optimized flow path architecture delivers unrestricted performance matching full tubing ID capacity;
4. Tool-less push-to-connect mechanism enables rapid installation while maintaining vibration-resistant leakproof connections.
Category: Y-Type Tee Fittings , Brand: AIRTAC , Series: APY
Installation protocol:
Apply 0.5-0.8Nm torque during installation. Use thread sealant only on male threads,
keeping 1.5mm distance from first thread crest. Perform pressure test at 110% of
working pressure after assembly.
2. Comprehensive model range with multiple specifications accommodates diverse pneumatic system requirements;
3. Optimized flow path architecture delivers unrestricted performance matching full tubing ID capacity;
4. Tool-less push-to-connect mechanism enables rapid installation while maintaining vibration-resistant leakproof connections.
Category: Y-Type Tee Fittings , Brand: AIRTAC , Series: APY
AirTAC APY Series Y-Type Tee Connector APY8 Technical Details
- Model: APY8
- Type: Y-shaped triple port pneumatic connector
- Thread standard: Metric (M5×0.8) / Optional NPT1/8
- Material: Brass with nickel plating (base), NBR seals
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 18.5±0.5g
- Dimensions: 20.5mm(L) × 19.8mm(W) × 24.3mm(H)
- Surface roughness: Ra0.8μm (sealing areas)
- Leakage rate: <0.1 mL/min under 0.5MPa
- Certification: ISO 6150-B standard compliant
Precision-engineered Y-connector featuring 120° branch angle for optimized airflow distribution. The chamfered entry ports (R0.3mm) prevent O-ring damage during assembly. Nickel-plated surface provides corrosion resistance in humid environments.
Common Implementations:
- Pneumatic circuit branching in SMT equipment
- Vacuum system flow division for robotic end effectors
- Modular pneumatic manifold assemblies
- Compressed air distribution in dental chairs
- Laboratory gas mixing stations
Installation protocol:
Apply 0.5-0.8Nm torque during installation. Use thread sealant only on male threads,
keeping 1.5mm distance from first thread crest. Perform pressure test at 110% of
working pressure after assembly.
Flow Characteristics:
- Cv value: 0.12 (pressure drop ΔP=0.1MPa)
- Effective flow area: 1.8mm²
- Pressure drop curve: Linear up to 0.8MPa
| Property | Property Value |
|---|---|
| sku | APY8 |
