Airtac BB Double Male Thread Straight Connector BB0202
The AirTAC Airtac BB Double Male Thread Straight Connector BB0202 is a genuine male / male connector rated to 3.0 MPa proof pressure and 0 to +150 °C, for joining threaded pipe runs.
- TypeMale / male connector
- SeriesBB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure3.0 MPa
- Temperature0 to +150 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac BB Double Male Thread Straight Connector BB0202
The BB0202 is a straight male connector: a single nickel-plated body with a male 1/4in PT thread on each end, used to join two fixed 1/4in ports or extend a run of 1/4in pipework in a straight line. There is no tube side at all - both ends are threads - so the joint is made up permanently with the pipework rather than plugged with hose.
This family sits apart from one-touch resin fittings: proof pressure is 3.0 MPa, twice the one-touch figure, working pressure runs 0-1.0 MPa, vacuum is rated to -750 mmHg (10 Torr), and the temperature window is 0 to +150 C. That combination is why BB0202 turns up close to ovens, dryers and moulding tools where a push-in body would soften or blow off. One caution when fitting: AirTAC publishes no tightening torque for this part, so assemble with a suitable PT thread sealant and tighten to a sound, leak-free joint by feel.
Airtac BB Double Male Thread Straight Connector BB0202 Technical Specifications
| Model | Airtac BB Double Male Thread Straight Connector BB0202 |
|---|---|
| Type | Male / male connector |
| Series | BB |
| Connection | Threaded both ends |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 3.0 MPa |
| Temperature | 0 to +150 °C |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
Nickel-plated metal body. AirTAC does not publish a per-part material breakdown for this family. This family is rated to 150 °C, but the TUBE is usually the limit - confirm your tubing's temperature rating before running it hot. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac BB Double Male Thread Straight Connector BB0202
| BB | Male / male connector. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac BB Double Male Thread Straight Connector BB0202 Is Used
Compressor aftercooler take-off
Joining 1/4in PT pipe runs downstream of an aftercooler, where the air is still well above 70 C and a resin push-in fitting would distort or loosen over time.
Autoclave and steriliser services
Extending 1/4in pneumatic or instrument air lines on steam-adjacent sterilising plant, using the 0 to +150 C window for the hot zone outside the chamber jacket.
Injection mould tool air blast
A fixed 1/4in-to-1/4in air-blast connection on a moulding tool, where vibration and mould heat punish push-in fittings and a threaded joint clamped once stays put.
Is the Airtac BB Double Male Thread Straight Connector BB0202 the Right Part?
BB0202 is the 1/4in-to-1/4in equal-size member of a nine-part BB ladder. Step down to BB0101 or BB0102 (1/8in ends, or 1/8in to 1/4in) for compact instrument panels and small actuators; step up to BB0203 (1/4in to 3/8in) or BB0303 (3/8in to 3/8in) when the run feeds larger-bore pipework and you need more capacity, which scales with the bore. Pick the equal 0202 when both ports are already 1/4in - it keeps the flow path straight with no reduction. If one side is female, a BD0202 does not exist in this range, so check the BD ladder (0102 up to 0304) or add a separate adapter.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within 0 to +150 °C
Airtac BB Double Male Thread Straight Connector BB0202 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2); vacuum to -750 mmHg (10 Torr); proof pressure 3.0 MPa; operating temperature 0 to +150 C; body nickel-plated with a male 1/4in PT thread on both ends (ordering code 0202). No flow value is published - capacity follows the straight 1/4in bore, so for larger flows step up to BB0203 or BB0303.
The threads are PT (R-seal taper) only - there is no NPT or G variant of this part, so use a PT-compatible sealant or tape. Slide the joint onto the first port, thread both ends hand-tight, then wrench each down evenly. AirTAC publishes no torque figure for this family; tighten until the taper seats and the joint is leak-free under 1.0 MPa, rechecking after the first hot cycle.
