Airtac BB Double Male Thread Straight Connector BB0202-S
SUS304 stainless variant (-S)The AirTAC Airtac BB Double Male Thread Straight Connector BB0202-S is a genuine male / male connector rated to 3.0 MPa proof pressure and 0 to +150 °C, for joining threaded pipe runs.
- TypeMale / male connector
- SeriesBB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure3.0 MPa
- Temperature0 to +150 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac BB Double Male Thread Straight Connector BB0202-S
The BB0202-S is a straight male connector in solid SUS304 stainless steel, joining two 1/4in PT male threads back to back. It screws into any 1/4in PT port and presents another 1/4in male thread on the far side, so it is the part you reach for when a hot or corrosive line has to be made up from threaded ports rather than push-in fittings.
This family is built past the point where push-in resin joints give up: working pressure to 1.0 MPa, proof pressure 3.0 MPa - three times the working ceiling - usable under vacuum down to -750 mmHg, and a temperature window of 0 to 150 C. The -S suffix replaces the family's usual nickel-plated finish with stainless 304 throughout, which is why this SKU shows up in wash-down plant, steam-adjacent lines and copper-free electronics or plating work. Use sealant on the PT taper threads; the fitting itself needs no torque figure and none is published.
Airtac BB Double Male Thread Straight Connector BB0202-S Technical Specifications
| Model | Airtac BB Double Male Thread Straight Connector BB0202-S |
|---|---|
| Type | Male / male connector |
| Series | BB |
| Connection | Threaded both ends |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 3.0 MPa |
| Temperature | 0 to +150 °C |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
Nickel-plated metal body. AirTAC does not publish a per-part material breakdown for this family. This family is rated to 150 °C, but the TUBE is usually the limit - confirm your tubing's temperature rating before running it hot. Stainless (-S): SUS304 body throughout, for copper-free and corrosive environments. Pressure and temperature ratings are unchanged from the nickel-plated version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac BB Double Male Thread Straight Connector BB0202-S
| BB | Male / male connector. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac BB Double Male Thread Straight Connector BB0202-S Is Used
Plating and surface-treatment lines
Copper-free SUS304 keeps the 1/4in air and rinse lines around pickling tanks and electroplating jigs free of copper contamination, surviving splash zones where plated fittings would pit.
Commercial dishwashing and wash-down plant
On conveyor dishwashers and food-line rinse manifolds, the 1/4in PT both-male format bridges actuator ports to stainless headers while shrugging off daily caustic washdown at up to 150 C ambient.
Thermoformer vacuum and blow-off circuits
Rigid SUS304 joints on the 1/4in ports of vacuum cups and mould-cooling blow-off lines hold -750 mmHg vacuum and 1.0 MPa working pressure on the hot platen side where resin push-ins creep.
Is the Airtac BB Double Male Thread Straight Connector BB0202-S the Right Part?
Step down from 1/4in x 1/4in and the smallest mixed neighbour is BB0102-S territory - the 1/8in x 1/4in reducing male connector - or BB0101-S if both ports are 1/8in; expect a smaller through-bore and lower capacity feeding compact tools or sensor ports. Step up and BB0203-S gives 1/4in x 3/8in, with BB0303-S the all-3/8in equal pair; the larger thread suits mains-fed headers where a tighter bend radius matters less than flow headroom. If one of the two ports must stay female, the BD male-and-female family removes the need for a separate coupling nut; and if the second port is simply unused, an honest answer is the BZ plug rather than a connector capped with tape.
All threads in this series are PT taper - no NPT or G variants exist - so sealant choice should suit the Japanese PT form, not a parallel G.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within 0 to +150 °C
Airtac BB Double Male Thread Straight Connector BB0202-S FAQ
It is a straight male connector with 1/4in PT male threads on both ends, body machined in SUS304 stainless steel. Working pressure is 0 to 1.0 MPa (0 to 10 kgf/cm2), negative pressure to -750 mmHg (10 Torr), proof pressure 3.0 MPa, and the permitted temperature range is 0 to 150 C. Ratings are identical to the nickel-plated BB0202; only the material changes.
Yes. The -S suffix changes the material to SUS304 only - dimensions, thread form and pressure figures all match the standard BB0202, so it drops straight into the same 1/4in PT port. Note the threads are PT taper, so apply thread sealant and tighten with a hex drive; AirTAC publishes no tightening torque for this family, so use good trade practice on a taper thread.
