Airtac BB Double Male Thread Straight Connector BB0303-S
AirTAC BB0303-S Double Male Thread Straight Connector Technical Details
- Model: BB0303-S
- Type: Double male thread straight-through fitting
- Thread standard: Metric (M) & PT (BSPP) options
- Primary thread size: M5×0.8 & PT1/8 (parallel threads)
- Material: C3604 lead-free brass (RoHS compliant)
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure rating: 0.05-1.5 MPa (7-217 psi)
- Temperature range: -20℃ to 120℃ (continuous use)
- Proof pressure: 3.0 MPa (435 psi)
- Burst pressure: ≥6.0 MPa (870 psi)
- Seal type: Metal-to-metal sealing (no O-ring required)
- Tightening torque: 1.0-1.5 N·m (M5), 1.5-2.0 N·m (PT1/8)
- Weight: 18.5±0.5g
- Dimensions: 30mm (L) × 12mm (Ø body) × 9mm (hex width)
- Flow coefficient (Cv): 0.12
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: ISO 8434-1, DIN 3852-2
Precision-machined transition fitting for hybrid pneumatic systems requiring metric-to-BSPP thread conversion. Features 6mm wrench flats for tool engagement and chamfered ports to prevent tube abrasion. The cold-forged brass construction ensures 250% higher fatigue strength compared to standard fittings.
- Interconnecting ISO 15407 and JIS B8381 components
- Retrofitting European machinery in Asian manufacturing lines
- Vacuum system instrumentation connections
- Medical gas panel distribution blocks
- Robotic end-effector tool changers
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads starting from second groove.
Use backup wrench on hex body during assembly to prevent torsion damage.
Pressure test at 1.1× system pressure for 10 minutes post-installation.
| Property | Property Value |
|---|---|
| sku | BB0303-S |
