Airtac BPC Metal Straight Connector BPC1203
$6.53
Regular price
$14.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BPC1203
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Constructed with all-metal threaded design, internal components contain brass; multiple models and specifications available, widely compatible with various pneumatic systems;
2. Features excellent flow characteristics achieving equivalent flow capacity to tube inner diameter;
3. Tool-free push-to-connect design enables fast tube installation, with secure and durable pneumatic tube connections;
4. M5 metric threads with integrated sealing washers ensure leak-free threaded connections;
5. Nickel-plated body provides corrosion resistance and contamination prevention, extending service life;
6. Full-metal construction ensures reliable performance in high-temperature environments.
Category: Threaded Straight Connectors , Brand: AirTAC , Series: BPC
Installation guidance:
Use proper thread sealant on male threads (except when using O-ring seal versions).
For metric threads, apply 25-35N axial force during tube insertion until audible click.
Maximum tube ovality tolerance: ±0.15mm.
2. Features excellent flow characteristics achieving equivalent flow capacity to tube inner diameter;
3. Tool-free push-to-connect design enables fast tube installation, with secure and durable pneumatic tube connections;
4. M5 metric threads with integrated sealing washers ensure leak-free threaded connections;
5. Nickel-plated body provides corrosion resistance and contamination prevention, extending service life;
6. Full-metal construction ensures reliable performance in high-temperature environments.
Category: Threaded Straight Connectors , Brand: AirTAC , Series: BPC
AirTAC BPC1203 Metal Straight Thread Fitting Specifications
- Model: BPC1203
- Material: Brass body with chrome plating (BSPP version)
- Thread standard: ISO 1179-1 (BSPP) / DIN 3852 (Metric)
- Port size: 1/8" BSPP (G1/8) or M10×1.0 metric thread
- Seal type: Integrated O-ring seal (NBR standard)
- Pressure rating: 0.05-1.6 MPa (7-232 PSI)
- Temperature range: -20℃ to 120℃ (with NBR seals)
- Proof pressure: 2.4 MPa (348 PSI)
- Surface treatment: Electroless nickel plating (3-5μm)
- Weight: 28g ±0.5g
- Dimensions: 25mm (L) × 12mm (W) × 12mm (H)
- Thread engagement: 8mm minimum
- Torque specification: 8-12 N·m (BSPP) / 10-14 N·m (Metric)
- Fluid compatibility: Air, inert gases, water (non-corrosive media)
- Certification: RoHS compliant
Precision-engineered metal push-to-connect fitting featuring triple sealing technology (radial seal + axial seal + thread seal). The 360° rotatable design allows flexible tube orientation adjustment after installation. Chrome-plated surface resists corrosion in humid environments.
Typical Applications:
- Pneumatic cylinder line connections
- Compressed air distribution systems
- Vacuum line quick-connect solutions
- Coolant line fittings in CNC machines
- Industrial robotic arm pneumatic networks
Installation guidance:
Use proper thread sealant on male threads (except when using O-ring seal versions).
For metric threads, apply 25-35N axial force during tube insertion until audible click.
Maximum tube ovality tolerance: ±0.15mm.
| Property | Property Value |
|---|---|
| sku | BPC1203 |
| Port Size | 12mm |
| Connection Thread | PT3/8 |
