Airtac BPC Metal Straight Connector BPC401
2. Features excellent flow characteristics achieving equivalent flow capacity to tube inner diameter;
3. Tool-free push-to-connect design enables fast tube installation, with secure and durable pneumatic tube connections;
4. M5 metric threads with integrated sealing washers ensure leak-free threaded connections;
5. Nickel-plated body provides corrosion resistance and contamination prevention, extending service life;
6. Full-metal construction ensures reliable performance in high-temperature environments.
Category: Threaded Straight Connectors , Brand: AirTAC , Series: BPC
AirTAC BPC401 Metal Straight Thread Connector Specifications
- Model: BPC401 Series
- Type: Reusable metal straight thread connector
- Thread Standard: PT/NPT/G (varies by variant)
- Port Sizes:
- PT1/8 (BPC401-01)
- PT1/4 (BPC401-02)
- PT3/8 (BPC401-03)
- Custom sizes available
- Material: Brass with nickel plating (standard), 304SS optional
- Max Working Pressure: 1.5 MPa (21.7 psi)
- Temperature Range: -20℃ to 120℃
- Seal Material: NBR (standard), FKM available
- Surface Treatment: Electroless nickel plating (5-8μm)
- Weight: 18g (PT1/8), 35g (PT1/4), 52g (PT3/8)
- Dimensions (PT1/8 variant):
- Length: 28mm
- Width: 12mm (hexagon flat-to-flat)
- Height: 12mm
- Certification: RoHS compliant
- Rotational Capability: 360° swivel function
Precision-engineered metal connectors featuring triple-sealing structure (thread + O-ring + metal-to-metal contact) for leak-free performance in high-vibration environments. The 6-point wrench flats enable secure installation without slippage. Nickel-plated version resists oxidation while stainless steel variants handle corrosive media.
- Pneumatic tool air supply lines
- CNC machine coolant systems
- Hydraulic test bench connections
- Semiconductor gas delivery systems
- High-cycle automation equipment
Installation protocol:
Apply PTFE tape to male threads (except when using O-ring seal variants).
Torque to 12-15 N·m for PT1/8 size. Perform pressure test at 1.1x system
pressure after installation. Replace O-rings every 5,000 connection cycles.
| Property | Property Value |
|---|---|
| sku | BPC401 |
| Port Size | <4mm> |
| Connection Thread | PT1/8 |
