Airtac BPC Metal Straight Connector BPC602
2. Features excellent flow characteristics achieving equivalent flow capacity to tube inner diameter;
3. Tool-free push-to-connect design enables fast tube installation, with secure and durable pneumatic tube connections;
4. M5 metric threads with integrated sealing washers ensure leak-free threaded connections;
5. Nickel-plated body provides corrosion resistance and contamination prevention, extending service life;
6. Full-metal construction ensures reliable performance in high-temperature environments.
Category: Threaded Straight Connectors , Brand: AirTAC , Series: BPC
AirTAC BPC602 Metal Straight Threaded Connector Specifications
- Model: BPC602
- Type: Metal-to-metal straight through connector
- Thread Standard: Metric (M5×0.8) / Optional NPT/PT/BSPP
- Material: Brass with nickel plating (C3604+Ni)
- Pressure Rating: 1.5 MPa (15 bar) maximum
- Temperature Range: -20℃ to 120℃
- Seal Type: Metal-to-metal sealing (no O-ring required)
- Surface Hardness: ≥HV200
- Thread Engagement: 4.5±0.5 turns
- Weight: 24±2 grams
- Dimensions: 28mm(L) × 12mm(OD) × 8mm(ID passage)
- Certification: ISO 8434-1/DIN 2353 industrial standard
Precision-machined metal connector designed for high-pressure pneumatic and hydraulic systems. Features zero-leakage metal sealing interface with 360° radial compression, ideal for vibration-prone environments. The nickel-plated surface provides enhanced corrosion resistance against water, oils, and mild chemicals.
- CNC machine tool pneumatic circuits
- Hydraulic test bench connections
- Robotic arm end-effector air supply
- High-cycle automation equipment
- Compressed air distribution manifolds
Installation guidance:
Apply thread sealant to male threads (Loctite 577 recommended).
Tighten to 1.2-1.6 N·m torque using backup wrench on hex body.
Avoid overtightening - seal is achieved through radial compression, not axial force.
| Property | Property Value |
|---|---|
| sku | BPC602 |
| Port Size | <6mm> |
| Connection Thread | PT1/4 |
