Airtac BPC Metal Straight Connector BPC603
2. Features excellent flow characteristics achieving equivalent flow capacity to tube inner diameter;
3. Tool-free push-to-connect design enables fast tube installation, with secure and durable pneumatic tube connections;
4. M5 metric threads with integrated sealing washers ensure leak-free threaded connections;
5. Nickel-plated body provides corrosion resistance and contamination prevention, extending service life;
6. Full-metal construction ensures reliable performance in high-temperature environments.
Category: Threaded Straight Connectors , Brand: AirTAC , Series: BPC
AirTAC BPC603 Metal Straight Thread Connector Specifications
- Model: BPC603
- Type: Reusable metal straight-through fitting
- Body material: Brass (CuZn39Pb3) with nickel plating
- Thread standard: Metric M5×0.8 (parallel thread)
- Seal type: EPDM O-ring (replaceable)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 150℃ (static) / -10℃ to 80℃ (dynamic)
- Fluid compatibility: Air, inert gases, water (non-corrosive media)
- Surface hardness: HV200-250
- Weight: 18.5±0.3g
- Dimensions: 24mm(Length) × 14mm(Width) × 14mm(Height)
- Thread engagement: 6mm minimum
- Vibration resistance: 10-2000Hz, 20G acceleration
High-pressure brass connector featuring double-sealing structure with primary metal-to-metal contact and secondary elastomer seal. The hexagon body design allows 360° installation flexibility using standard wrenches. Nickel plating provides corrosion resistance exceeding 96hrs in salt spray tests.
- Pneumatic cylinder port connections
- Instrumentation air sampling lines
- Coolant line junctions in CNC machinery
- Vacuum system interconnects
- Hydraulic test bench fittings (low-viscosity fluids)
Installation note:
Apply 0.8-1.2Nm torque during assembly. For gas applications,
orient the fitting with O-ring positioned downstream.
Replace O-rings every 5,000 pressure cycles or 2 years.
| Property | Property Value |
|---|---|
| sku | BPC603 |
| Port Size | <6mm> |
| Connection Thread | PT3/8 |
