Airtac BSAID Clamp Cylinder BSAID100X175S
2. Enables secure locking and stopping at any intermediate position within the stroke range;
3. Features optimized locking mechanism design ensuring direction-independent locking performance regardless of piston movement orientation.
Category: Standard Cylinders , Brand: AirTAC , Series: BSAID
AirTAC BSAID100X175S Clamp Cylinder Specifications
- Model: BSAID100X175S
- Type: Double-acting clamp cylinder (ISO standard)
- Bore size: Ø100 mm
- Stroke: 175 mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Standard flange mounting (MF1 pattern)
- Port size: PT1/2 (G1/2 optional)
- Piston rod thread: M20×1.5
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated carbon steel
- Seals: NBR (nitrile rubber)
- Weight: 3.85 kg (dry)
- Dimensions:
- Total length: 298 mm (at full retraction)
- Extended length: 473 mm (stroke + base length)
- Flange width: 160 mm
- Mounting hole spacing: 125×125 mm
- Rod end thread length: 30 mm
High-precision clamping cylinder with reinforced rod bearing design, optimized for vertical load applications. Features dual anti-rotation guides (integrated keyway) for precise positioning during clamping operations. Includes wear-resistant scraper seal for debris protection. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Fixture clamping in CNC machining centers
- Workpiece positioning in die-casting machines
- Pallet locking systems in automated warehouses
- Mold clamping in injection molding equipment
- Press brake tool holding systems
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use torque wrench for flange bolts (45-50 N·m).
Lubricate rod with EP2 grease weekly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | BSAID100X175S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 175mm |
| Static Holding Force | 5500N |
