Airtac CM3HS Selector Mechanical Valve CM3HS05R
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS Selection-Type Mechanical Valve CM3HS05R Technical Details
- Model: CM3HS05R
- Type: 3-position selector valve (Mechanical spring return)
- Port configuration: 5 ports (P, A, B, R1, R2)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–1.0 MPa
- Max flow rate: 600 NL/min (ANR)
- Operating temperature: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Actuation force: 30N ±10%
- Weight: 215g ±5%
- Dimensions: 53mm(L) × 34mm(W) × 42mm(H)
- Mounting style: Panel mount with M4 screw holes
- Protection class: IP67 (dust/water resistant)
- Compliance: RoHS 2.0 compliant
Industrial-grade mechanical selector valve featuring triple-position control (center closed position) with positive mechanical detents. Engineered for high-cycle applications requiring manual or mechanical actuation, with wear-resistant components rated for 2 million cycles. Features dual exhaust ports for efficient air discharge and anti-vibration lock mechanism.
- Jig fixture clamping sequence control
- Pneumatic tool selector systems
- Production line emergency stop circuits
- Material handling diverters
- Textile machinery pattern selectors
Installation guidelines:
Mount in accessible location with lever actuation direction matching operator access.
Use lock washers on mounting screws for vibration-prone environments.
Lubricate pivot points every 50,000 cycles with ISO VG32 hydraulic oil.
