Airtac CM3PL Detent Rotary Button Type Mechanical Valve CM3PL08G
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for versatile application scenarios.
3. Poppet valve structure ensures superior sealing performance, smooth shifting action, and maintenance-free lubrication.
4. Supports multi-position mounting configurations for flexible installation and operation.
5. CM3L, CM3V, CM3R, and CM3Y series employ metal actuator heads for extended service life and enhanced operational reliability.
6. CM3PMS and CM3PMX models incorporate metal protective covers to safeguard button caps against accidental actuation and mechanical interference, ensuring fail-safe performance.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PL Park & Rotate Button Mechanical Valve
AirTAC CM3PL08G Parking Rotary Button Mechanical Valve Specifications
- Model: CM3PL08G
- Type: 3-position detent rotary valve (Lockable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Operating temperature: -5℃ to 60℃ (23℉ to 140℉)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Mounting style: Panel mount with M5 screw holes
- Rotation torque: ≤1.5 N·m
- Weight: 350g ±5% (0.77 lbs)
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H)
- Port thread depth: 12mm
- Actuation angle: 90° per position
- IP rating: IP54 (dust protected, water splashed)
- Compatible fluids: Air, inert gases (non-lubricated)
Manual rotary valve with positive detent mechanism for precise pneumatic circuit control. Features a knurled stainless steel knob with position indicators (A/B/Exhaust) and integrated locking pin to prevent accidental operation. The hardened brass internal mechanism ensures 500,000+ cycle durability. Requires 5-15Nm mounting torque.
- Emergency stop/pressure release in production lines
- Manual mode switching in automated machinery
- Air flow direction control in material handling systems
- Testing bench pneumatic circuit isolation
- Safety lockout during equipment maintenance
Installation note:
Apply thread sealant (PTFE tape) on port threads. Ensure detent ball
aligns with position marks before final tightening. Lubricate rotating
shaft monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | CM3PL08G |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
