Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS05Y
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS05Y Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMS05Y
- Type: Push-button mechanical valve with emergency stop function
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Operating medium: Filtered air (max 50μm particles)
- Actuation force: 30–50N (mechanical lock type)
- Body material: Reinforced POM (Polyoxymethylene)
- Button material: Stainless steel 304
- Temperature range: -10℃ to 70℃
- Mounting style: Panel mount (22mm cutout diameter)
- Protection rating: IP67 (dust/water resistant)
- Mechanical life: ≥500,000 cycles
- Weight: 180g ±5g
- Dimensions: 42mm(D) × 42mm(H) × 58mm(Projection)
Industrial-grade emergency stop valve featuring twist-to-release mushroom head design with positive mechanical latching. The bright red anodized aluminum collar provides visual safety status indication. Integrated O-ring (NBR) ensures reliable sealing even in high-vibration environments.
- Production line emergency stop stations
- Injection molding machine safety systems
- Automated warehouse conveyor controls
- Robotic cell safety interlocks
- Press machine two-hand control setups
Installation note:
Requires 3mm thick minimum panel surface. For vertical mounting,
ensure cable entry orientation matches environmental protection needs.
Test mechanical reset function weekly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | CM3PMS05Y |
| Position | 3-Port 2-Position |
| Port Size | M5 |
