Airtac CM3PMS Mushroom Head Push Button Mechanical Valve CM3PMS08Y
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual override with multi-configuration actuators for diverse operational conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication;
4. Multi-directional mounting options enhance installation flexibility;
5. CM3L, CM3V, CM3R, and CM3Y series adopt metallic actuators for extended service life and superior reliability;
6. CM3PMS and CM3PMX series incorporate an integrated protective metal shroud to shield the button cap, preventing accidental actuation and ensuring operational safety.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PMS
AirTAC CM3PMS08Y Mushroom Head Push Button Mechanical Valve Specifications
- Model: CM3PMS08Y
- Type: 3/2-way normally closed mechanical valve (manual reset)
- Operation style: Mushroom head push button with emergency stop function
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure range: 0.15–0.8 MPa
- Operating force: ≤50N (per EN 60947-5-5)
- Flow capacity: 750 l/min (ANR)
- Body material: Nickel-plated brass
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Mechanical life: ≥500,000 cycles
- Contact rating: 1A/24VDC (gold-plated contacts)
- Protection rating: IP67 (dust/water resistant)
- Weight: 215g ±5g (including mounting hardware)
- Dimensions: 54mm(D) × 54mm(W) × 82mm(H) (button protrusion: +15mm)
- Mounting: M5 threaded holes (4x) on 40mm square pattern
Emergency safety valve with oversized 38mm mushroom head for rapid system shutdown. Features positive mechanical latching requiring manual twist-reset operation. Corrosion-resistant construction with dual O-ring sealing ensures reliable performance in harsh environments. Includes dual redundant contacts for safety circuit integration.
- Industrial machinery emergency stop systems
- Press brake safety interlocks
- Automated production line safety gates
- Robotic cell emergency cutoff
- Packaging equipment jam recovery systems
Installation guidelines:
Mount within 600mm horizontal reach of operator position. Maintain minimum 25mm
clearance around button perimeter. Test monthly for positive engagement and
smooth reset action. Lubricate shaft quarterly with silicone grease (ISO VG 10).
| Property | Property Value |
|---|---|
| sku | CM3PMS08Y |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
