Airtac CM3PMX Large Mushroom Head Button Type Mechanical Valve CM3PMX05Y
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations, enabling flexible deployment under various working conditions.
3. Poppet valve design ensures superior sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements.
4. Supports multiple mounting orientations for simplified installation and space optimization.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and reliable long-term performance.
6. CM3PMS and CM3PMX series are equipped with metal protective covers to shield the pushbutton cap from accidental impacts and prevent unintended actuation, ensuring operational safety and reliability.
Category: Mechanical Valves, Brand: AIRTAC, Series: CM3PMX
AirTAC CM3PMX Mushroom Head Push Button Mechanical Valve CM3PMX05Y Specifications
- Model: CM3PMX05Y
- Type: 3/2-way manual reset mechanical valve (push-to-lock)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–1.0 MPa
- Operating force: 30-50N (ergonomic activation)
- Mechanical life: ≥500,000 cycles
- Temperature range: -10℃ to 80℃
- Protection rating: IP67 (dust/water resistant)
- Body material: Stainless steel 304 + PBT polymer
- Seal material: Oil-resistant NBR
- Weight: 280g ±5g
- Dimensions: 48mm(D) × 48mm(W) × 82mm(H)
- Mounting: Panel mounting (22mm cutout)
- Contact rating: 5A 250VAC (gold-plated contacts)
Emergency stop valve with oversized 40mm yellow mushroom head for immediate system shutdown. Features positive-locking mechanism requiring manual twist-release for reset. Rugged zinc-plated spring and corrosion-resistant construction ensures reliability in harsh environments. Integrated LED status indicator (optional).
- Industrial machinery emergency stop systems
- Press brake safety controls
- Conveyor line emergency cutoff
- Robotic cell safety interlocks
- Training simulator safety panels
Installation note:
Requires 360° accessibility for emergency operation.
Monthly function test recommended.
Use M4 stainless steel mounting hardware (not included).
Compatible with 1.5mm²–2.5mm² conductor wiring.
| Property | Property Value |
|---|---|
| sku | CM3PMX05Y |
| Position | 3-Port 2-Position |
| Port Size | M5 |
