Airtac GVR Vacuum Pressure Regulating Valve GVR20006
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Stable pressure regulation with minimal pressure deviation and excellent pressure characteristics;
3. Supports both panel mounting and optional fixed bracket installation.
Category: Vacuum Regulating Valve, Brand: AIRTAC, Series: GVR
AirTAC GVR20006 Vacuum Regulator Specifications
- Model: GVR20006
- Type: Precision vacuum pressure regulator
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: -100kPa to 0.8MPa
- Maximum vacuum level: -98kPa (at 20℃)
- Flow capacity: 700 NL/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Diaphragm material: Fluororubber (FKM)
- Temperature range: -10℃ to 60℃ (non-freezing)
- Weight: 480g ±5%
- Dimensions: 98mm(H) × 60mm(W) × 46mm(D)
- Thread engagement depth: 12mm (minimum)
- Pressure gauge interface: Rc1/8
- Protection rating: IP40 (standard)
High-sensitivity vacuum regulator with dual pressure gauge ports and fine-adjustment knob (1.5 rotations for full scale). Features anti-vibration structure with lockable setting and integrated silencer. Compatible with vacuum pumps requiring ±2% pressure stability. Requires upstream 5μm filtration.
- PCB handling vacuum gripper systems
- Medical suction equipment pressure control
- Glass panel CNC machining fixtures
- Automated packaging line pick-and-place units
- Semiconductor wafer processing stations
Installation note:
Mount vertically with arrow direction matching airflow. Allow 50mm clearance
below gauge ports for maintenance. Lubricate threads with PTFE tape only.
Critical:
Not compatible with phosphate ester fluids or oxidizing gases.
Perform weekly diaphragm checks in continuous vacuum applications.
| Property | Property Value |
|---|---|
| sku | GVR20006 |
| Port Size | PT1/8 |
