Airtac M3HS Selector Mechanical Valve M3HS11006R
2. M3B/M3R/M3L series utilize externally supplied directional switching force, suitable for position detection or limit switch applications;
3. M3C/M3D/M3Y/M3PF/M3PM/M3PP/M3PL/M3HS series feature manual operation with multiple structural configurations for diverse operational requirements;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure effect), enhanced by internal ring sealing for reliable performance and smooth directional switching;
5. Oil-free lubrication system eliminates maintenance requirements;
6. Multi-position mounting capability ensures flexible installation options;
7. M3C/M3D/M3Y/M3R/M3I series incorporate durable metal actuators for extended service life and enhanced operational stability.
Category: Mechanical Valves | Brand: AirTAC | Series: M3HS
AirTAC M3HS11006R Selector Mechanical Valve Technical Details
- Model: M3HS11006R
- Type: 3-position selector valve (Mechanical spring return)
- Port configuration: 5/3-way closed center
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 750 L/min (Cv=1.3)
- Actuation force: 50N±10% manual lever operation
- Weight: 185g±5g (with accessories)
- Dimensions: 54mm(L) × 38mm(W) × 76mm(H)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 120℃ (dry air conditions)
- Response time: ≤50ms (pressure-dependent)
- Protection rating: IP67 (dust/immersion proof)
- Mounting options: Panel mount with M4 screws (included)
Industrial-grade mechanical selector valve featuring triple-position control (center block function) for complex pneumatic circuits. The hardened stainless steel shaft and wear-compensation design ensure 500,000+ cycles lifespan. Optimized flow paths reduce pressure drop by 18% compared to previous generations. Requires ISO8573-1 Class 3.4.2 air quality.
- Multi-station fixture clamping systems in CNC machining
- Safety interlocks for press machine tooling
- Material handling equipment with manual override needs
- Textile machinery pattern selection mechanisms
- Food processing line diverters (FDA-compliant grease option available)
Installation guidelines:
Mount in vibration-controlled environments (max 5G acceleration).
For horizontal mounting, install drip shield (accessory M3HS-SHIELD).
Perform monthly lubrication with PAG-based grease (2ml max).
| Property | Property Value |
|---|---|
| sku | M3HS11006R |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
