Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM11006G
$20.90
Regular price
$28.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
M3PM11006G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Mushroom Head Push Button Mechanical Valve M3PM Series (Airtac Brand)**
1. Exhaust ports integrated into the valve body facilitate silencer installation, reducing noise and environmental pollution;
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
Installation note:
Requires 360° accessible clearance around button head for emergency operation.
Apply thread sealant (PTFE tape recommended) on port threads.
Monthly function test advised for safety-critical applications.
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM11006G Mushroom Head Push Button Mechanical Valve Specifications
- Model: M3PM11006G
- Type: 3/2-way normally closed (manual reset)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Actuation force: 50N ±10% (button press)
- Reset mechanism: Spring return
- Body material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃ (operating fluid)
- Flow rate: 350 NL/min (at 0.5 MPa)
- Weight: 210g ±5% (including accessories)
- Dimensions: 48mm(L) × 48mm(W) × 76mm(H)
- Mounting style: Panel mounting (15mm cutout)
- Protection rating: IP67 (dust/water resistant)
- Operating cycles: ≥500,000 (under rated conditions)
Emergency-stop style mechanical valve with positive tactile feedback, featuring a 30mm diameter red mushroom head for quick activation. The zinc alloy spring mechanism ensures reliable resetting even in high-vibration environments. Integrated O-ring provides panel seal when installed.
Typical Applications:
- Emergency stop systems in CNC machinery
- Safety interlocks for press equipment
- Manual override in automated production lines
- Pneumatic system maintenance lockout
- Test bench pressure release control
Installation note:
Requires 360° accessible clearance around button head for emergency operation.
Apply thread sealant (PTFE tape recommended) on port threads.
Monthly function test advised for safety-critical applications.
| Property | Property Value |
|---|---|
| sku | M3PM11006G |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
