Airtac M3PM Mushroom Head Push Button Mechanical Valve M3PM21006B
$26.74
Regular price
$34.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
M3PM21006B
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Mushroom Head Push Button Mechanical Valve M3PM Series (Airtac Brand)**
1. Exhaust ports integrated into the valve body facilitate silencer installation, reducing noise and environmental pollution;
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
Installation requirements:
Mount with 35-45N·m torque using included M5 mounting nuts.
Maintain 20mm clearance behind panel for cable routing.
Test reset function monthly - full 360° rotation required for reactivation.
2. The M3B, M3R, and M3L series require external mechanisms to provide shifting force, enabling position detection or travel switch applications;
3. The M3C, M3D, M3Y, M3PF, M3PM, M3PP, M3PL, and M3HS series feature manual operation with diverse control head structural configurations for versatile usage across conditions;
4. Spool-type design ensures consistent control force independent of working pressure (zero backpressure interference). Internal circumferential sealing delivers leak-tight performance and smooth shifting;
5. Lubrication-free operation eliminates maintenance requirements;
6. Supports multiple mounting orientations for flexible installation;
7. M3C, M3D, M3Y, M3R, and M3I series incorporate metal control heads for enhanced durability and operational stability.
**Category**: Mechanical Valves | **Brand**: Airtac | **Series**: M3PM
AirTAC M3PM Mushroom Head Push Button Mechanical Valve M3PM21006B Specifications
- Model: M3PM21006B
- Type: 3/2-way normally closed (manual reset)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.7 MPa
- Actuation force: 30-50N (emergency stop compliant)
- Body material: Nickel-plated brass
- Seal material: NBR/HNBR (optional FKM)
- Temperature range: -5℃ to 70℃
- Mounting type: Panel mount (6.5mm panel thickness max)
- Button diameter: 40mm (ISO 13850 compliant)
- Protection rating: IP65 (front side)/IP40 (rear side)
- Electrical connection: 2-pin M8 connector (optional lead wire)
- Mechanical life: ≥500,000 cycles
- Weight: 198g ±5g
- Dimensions: 56mm(L) × 40mm(W) × 48mm(H)
Emergency-stop mushroom head valve with positive mechanical latching mechanism. Features twist-to-reset operation and dual-color (red/yellow) indicator ring. The zinc alloy actuator head meets safety category 4/PL e per ISO 13849-1. Requires 2.5mm² wire for power connection.
Typical Applications:
- Machine emergency stop stations
- Assembly line safety interlocks
- Plastic injection molding machine controls
- Material handling system e-stops
- Packaging equipment safety circuits
Installation requirements:
Mount with 35-45N·m torque using included M5 mounting nuts.
Maintain 20mm clearance behind panel for cable routing.
Test reset function monthly - full 360° rotation required for reactivation.
| Property | Property Value |
|---|---|
| sku | M3PM21006B |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
