Airtac MTK Multi-position Locking Cylinder MTK16X20S
The AirTAC Airtac MTK Multi-position Locking Cylinder MTK16X20S is a genuine MK multi-mount cylinder (single acting, pull type), 16 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 60.5 N of pull force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, single acting, pull type
- SeriesMK (no-rotating)
- Bore16 mm
- Pull thrust @0.5 MPa60.5 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTK Multi-position Locking Cylinder MTK16X20S
The MTK16X20S is a compact multi-mount cylinder with a square body that fixes from six directions - front, back, left, right, top and bottom - so units sit side by side to save space, with magnetic-switch slots around the body. This model is a 16 mm bore, 20 mm stroke, single-acting pull-type cylinder from AirTAC's MK family: air retracts the rod, and a no-rotating plate with fixed rod stops the rod turning. It runs on air filtered to 40 um at 0.2-1.0 MPa (28-145 psi) at 50-500 mm/s, with a bumper cushion.
This is a genuine AirTAC part. The MK family is the no-rotating counterpart of the standard MD family, adding a no-rotating plate, brass bushing and fixed rod (typical construction; bore-specific detail is on the datasheet). The trailing S in the SKU means a magnet is built in, and the thread is PT. Dimensions vary with stroke, so we confirm dimensions and sizing from the datasheet on request.
Airtac MTK Multi-position Locking Cylinder MTK16X20S Technical Specifications
| Model | Airtac MTK Multi-position Locking Cylinder MTK16X20S |
|---|---|
| Type | Multi-mount cylinder, single acting, pull type |
| Series | MK (no-rotating) |
| Bore | 16 mm |
| Pull thrust @0.5 MPa | 60.5 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Choose MTK when air must retract the load rather than extend it: MTK is the single-acting, pull-type member of the no-rotating MK family, while MD stays standard and MSD/MSK push instead. The 16 mm bore operates at 0.2-1.0 MPa (28-145 psi); theoretical thrust for this bore and acting side is on the datasheet - ask us to confirm it. The trailing S gives you a magnet for switch position feedback; without the S the body has no magnet. Single-acting strokes in this bore run up to 20 mm and the covers are short, so avoid over-long strokes and route side-load questions to us. Thread is PT here; G is available.
Applications
Aligned pick-and-place probe
Use the non-turning rod to keep a small gripper or vacuum plate square during vertical pick-and-place moves, while the built-in magnet lets a switch confirm up and down positions in the body slots.
Indexed release stopper
Hold or release parts at a station on an indexing line: the no-rotating plate keeps the contact face square through the 20 mm retract stroke and the magnet feeds position signals to the controller.
Compact diverter row
Line up several magnet-fitted bodies side by side along a conveyor to drive short diverters, using the six-direction fixing to bolt each unit where frame space is tight.
FAQ
What does the S at the end of MTK16X20S mean?
The trailing S means this cylinder is built with a magnet, so magnetic switches seated in the slots around the body can sense rod position. The same cylinder without the S suffix has no magnet. MTK itself decodes as the single-acting, pull-type version of the no-rotating MK family, 16 mm bore, 20 mm stroke, PT thread.
How does the multi-mount body help in a tight build?
The square body fixes from six directions - front, back, left, right, top and bottom - so you can bolt it through whichever face suits the fixture and mount several units side by side to save space. For allowable side-load and exact stroke-dependent dimensions, confirm from the datasheet.
