Airtac NRV Non-Return Valve NRV08
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Prevents backflow phenomena caused by pressure decay in air supply systems or excessive consumption-induced pressure drops;
3、Features a large effective flow area for optimized pneumatic performance;
4、Incorporates injection-molded POM valve core and elastomer-sealed orifice, engineered with compact construction for reliability.
Category: Check Valves
Brand: AIRTAC
Series: NRV
AirTAC NRV Check Valve NRV08 Technical Specifications
- Model: NRV08
- Type: Spring-loaded poppet check valve
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–1.0 MPa
- Cracking pressure: 0.02 MPa (minimum)
- Max flow capacity: 400 L/min (ANR)
- Body material: Brass (C3604)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 98g ±2g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- Port thread depth: 10mm (both sides)
- Response time: <10ms
- Leakage rate: <5 bubbles/min (at 0.5 MPa)
High-flow compact check valve with low cracking pressure, featuring precision-machined brass body and spring-assisted closure mechanism. The 45° angled seat design minimizes pressure drop while maintaining rapid response. Compatible with air, inert gases, and vacuum applications. Includes integrated dust cap threads.
- Pneumatic circuit protection against backflow
- Compressor outlet safety systems
- Vacuum pump line isolation
- Air receiver tank safety valves
- Medical gas delivery systems
- Robotic actuator pressure maintenance
Installation guidelines:
Install with flow arrow aligned to system direction. Requires minimum 10mm straight piping upstream.
For vacuum applications, orient valve vertically with arrow pointing upward. Lubricate threads with PTFE tape
(max 1.5 wraps) and torque to 12-15 N·m. Test for seat leakage after 24hrs of operation.
| Property | Property Value |
|---|---|
| sku | NRV08 |
| Port | PT1/4 |
