Airtac NRV Non-Return Valve NRV10
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Prevents backflow phenomena caused by pressure decay in air supply systems or excessive consumption-induced pressure drops;
3、Features a large effective flow area for optimized pneumatic performance;
4、Incorporates injection-molded POM valve core and elastomer-sealed orifice, engineered with compact construction for reliability.
Category: Check Valves
Brand: AIRTAC
Series: NRV
AirTAC NRV Series One-Way Check Valve NRV10 Technical Details
- Model: NRV10
- Type: Spring-loaded poppet check valve
- Port thread: G1/8 (BSPP) female threads
- Pressure range: 0.05-1.0 MPa
- Cracking pressure: 0.01 MPa (minimum)
- Max flow capacity: 400 L/min (ANR)
- Body material: Aluminum alloy (anodized surface)
- Seal material: HNBR rubber (-20℃ to 120℃)
- Weight: 85g ±2g
- Dimensions: 32mm(L) × 24mm(W) × 38mm(H)
- Operating temperature: -20℃ to 80℃ (with silicone seals optional for -40℃)
- Viscosity range: ≤50 cSt
- Leakage rate: <3 bubbles/min (ISO 6953-1 test)
The NRV10 features a low cracking pressure design with precision-machined aluminum body for bidirectional flow blocking. Its asymmetric spring chamber design prevents particulate accumulation, making it ideal for contaminated air environments. The valve maintains consistent performance through 1 million cycles minimum.
- Air compressor return line protection
- Vacuum pump system backflow prevention
- Pneumatic cylinder exhaust port locking
- Medical gas distribution systems
- Hydraulic accumulator isolation (oil-resistant seals required)
- CNC machine tool air circuit safety
Installation guidelines:
Arrow direction must align with primary flow path. For vertical installation,
orient spring chamber downward. Use PTFE tape on male threads only,
avoiding entry into flow channels. Pre-flush pipelines before commissioning.
| Property | Property Value |
|---|---|
| sku | NRV10 |
| Port | PT3/8 |
