Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S
SUS304 stainless variant (-S)The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S
The PED1002-S is an AirTAC PED male run tee in the SUS304 stainless-steel variant, joining Dia 10 mm soft nylon or polyurethane tubing to a 1/4in PT male thread. A run tee differs from a branch tee in one important way: the tube path continues straight through the body while the threaded port tees off to the side, so the main line is not turned through 90 degrees. Push the Dia 10 tube home and the internal chuck grips it; press the release ring and it frees again.
Because this is a -S part, the male stud is stainless steel 304 while the body remains engineered PBT - the ratings are identical to the standard version: 0-1.0 MPa working pressure, -750 mmHg vacuum, 1.5 MPa proof pressure and -20 to +70 C. The 1/4in thread arrives with sealant already applied, so it seals straight into a PT port without extra tape.
Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S Is Used
Valve manifold branch on a bottling line
Mounted on the Dia 10 trunk feeding a rinse-and-fill carousel, the run tee lets the main airline pass straight through while the 1/4in stud drops a branch to the cylinder valve block, keeping the trunk free of extra elbows.
Palletising cell pick-and-place supply
On a robotic palletiser, the straight-through bore carries supply air past the wrist to the next drop while the side port feeds the vacuum ejector, so one fitting does both the pass-through and the branch at a Dia 10 take-off.
Plasma cutting table air drops
Along a plasma table's Dia 10 air spine, a run tee at each torch station passes the clean, dry air onward to the next station and tees a 1/4in feed off to the torch solenoid without disturbing the main line.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S the Right Part?
At the 1/4in thread, the PED ladder runs Dia 4, 6, 8, 10 and 12. Stepping down to PED802-S drops the bore to Dia 8, which suits shorter runs and lighter cylinder feeds; stepping up to PED1202-S opens the passage to Dia 12 for trunk lines where a straight-through flow path matters. Match the stud to the port: 1/4in PT into a 1/4in port, no adapters.
Tube OD must match exactly - a Dia 10 chuck will not seal on 3/8in or 12 mm tube. If you need the tee to sit flush through a panel instead of branching off a stud, the PM bulkhead union or PLM bulkhead elbow is the shape to look at; if you need the branch to turn rather than pass through, compare the PEB male branch tee.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED1002-S FAQ
It is an AirTAC PED male run tee for Dia 10 mm tubing with a 1/4in PT male thread. Working pressure is 0-1.0 MPa (0-10 kgf/cm2), negative pressure -750 mmHg (10 Torr), proof pressure 1.5 MPa and operating temperature -20 to +70 C. It takes soft nylon or polyurethane tube, and the -S suffix means the stud is stainless steel 304 while the body is PBT - the ratings are unchanged from the standard PED1002.
No. On the PED family the -S variant fits a SUS304 stainless male stud into the standard PBT body, which is why the pressure, vacuum and temperature figures match the plain PED1002 exactly. Only the PC and POC straight connectors get a solid 304 body in the stainless range. The practical benefit here is a corrosion-resistant, sealant-coated male thread where it meets the port, which matters in humid or wash-prone installations.
