Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S
SUS304 stainless variant (-S)The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S
The AirTAC PED1003-S is a male run tee in the PED one-touch fitting family. It screws a 3/8in PT male thread into a port, grips a Dia 10 mm tube in the run, and offers a Dia 10 mm branch at 90 degrees - so the main air line continues straight through while a single branch feeds off to the side. The -S suffix means the stud is SUS304 stainless steel instead of brass; the tee body itself stays glass-filled PBT, so this is a stud upgrade, not a solid stainless part.
This is a resin and brass line fitting, not the metal BP family: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg, proof pressure 1.5 MPa, and -20 to +70 C. To connect, push the Dia 10 mm tube straight into the chuck until it bottoms out - the stainless spring gasket and POM chuck grip it. Press the POM release ring toward the body and the tube pulls free. The 3/8in thread arrives with sealant pre-applied, so it seals straight into a PT port without extra tape.
Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S Is Used
Palletizer air drop
On a palletizing cell, the run tee carries the Dia 10 mm main line straight down the machine frame while the 90 degree branch feeds a vacuum or gripper circuit without adding a separate coupling.
Automotive fixture clamping
At a machining or assembly fixture, the 3/8in PT stud screws into the manifold port and the branch drops Dia 10 mm supply to a swing clamp, keeping the run intact for the next station.
Washdown food line branch
In a food-plant air ring washed down daily, the SUS304 stud stands up to moisture and cleaning agents where a plain brass stud would dull and corrode at the port seal.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S the Right Part?
On the PED 3/8in thread row you can step down to the PED803 (Dia 8 mm) or up to the PED1203 (Dia 12 mm). Dropping to Dia 8 trims the bore for lighter draws like pilot-air branches; stepping to Dia 12 suits the main feed of a larger machine. AirTAC also offers the PKD10-803 male reducer triple branch, which keeps a Dia 10 mm run but steps the branch down to Dia 8 - useful when one leg feeds a smaller actuator. Always match tube OD exactly: a Dia 10 mm chuck will not hold 3/8in imperial tube, which is 9.5 mm and roughly half a millimetre too small to seal.
Match the 3/8in PT thread to a port tapped for it; on smaller ports the PED ladder also offers 1/4in (up to Dia 12) and M5 (Dia 4 or 6 only). Note that M5 sizes seal with a gasket rather than the pre-applied thread sealant used on the pipe-thread sizes.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED1003-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a working temperature of -20 to +70 C. It joins a Dia 10 mm tube to a 3/8in PT male thread. The -S variant carries the same ratings as the standard PED1003 - only the stud material changes to SUS304.
No. The chuck and seal are cut for exactly 10 mm outside diameter, while 3/8in tube measures about 9.5 mm, so it will not seal or lock. Use soft nylon or polyurethane tube marked Dia 10 mm. Also note that even on the -S version the release ring and chuck remain POM resin - only the threaded stud is SUS304.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard parts are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
