Airtac PED T-Shaped Side Thread Tee Fitting PED1004
The AirTAC Airtac PED T-Shaped Side Thread Tee Fitting PED1004 is a genuine male run tee for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeMale run tee
- SeriesPED
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PED T-Shaped Side Thread Tee Fitting PED1004
The AirTAC PED1004 is a male run tee in the PED one-touch family. Two Dia 10 tube ends sit in a straight line through the body and a 1/2in PT male thread leaves at 90 degrees on the branch, so you can tap a controlled-air take-off without interrupting the main tube run. To make a joint, push the soft nylon or polyurethane tube home until it stops; the POM chuck grips the tube wall and the stainless spring gasket seals it. Pressing the release ring frees the tube again for rework.
This is the resin and brass spec profile, not the metal BP line: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a temperature window of -20 to +70 C. The body is PBT, the threaded stud is brass and arrives with sealant already on the thread, and the internal O-ring is NBR. Grey is the standard colour; a D suffix on other PED sizes changes the body to black.
Airtac PED T-Shaped Side Thread Tee Fitting PED1004 Technical Specifications
| Model | Airtac PED T-Shaped Side Thread Tee Fitting PED1004 |
|---|---|
| Type | Male run tee |
| Series | PED |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PED T-Shaped Side Thread Tee Fitting PED1004
| PED | Male run tee. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PED T-Shaped Side Thread Tee Fitting PED1004 Is Used
Tapping a cylinder feed on a bottling machine
Along a rinse-and-fill machine frame, the PED1004 lets a Dia 10 supply run pass straight through while its 1/2in PT branch drops air to a pick-and-place cylinder, all on one-touch tube ends that release for changeover.
Branch to a clamping vice on a bandsaw
A Dia 10 trunk line serving a workshop cell can keep running past the saw, and the threaded branch bolts into a 1/2in PT port on the pneumatic clamp circuit without cutting or re-routing the main run.
Gripper drop on a palletising robot
Where a Dia 10 tube trunk travels the length of the robot dress-pack, the inline run tee takes the 1/2in PT branch off at 90 degrees to feed gripper valve ports, so the main line stays straight and vibration-free.
Is the Airtac PED T-Shaped Side Thread Tee Fitting PED1004 the Right Part?
On the 1/2in thread row of the PED ladder your neighbours are PED804 (Dia 8 tube) and PED1204 (Dia 12 tube). Stepping down to Dia 8 gives a smaller bore suited to compact actuator legs; stepping up to Dia 12 suits heavier main runs - remember it is the tube bore, not the fitting shape, that sets the flow path. If your port is smaller than 1/2in, PED1002 (1/4in) and PED1003 (3/8in) carry the same Dia 10 tube on narrower studs. Match the port thread first, then order for exact tube OD: a Dia 10 chuck will not seal on 12mm or 3/8in tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PED T-Shaped Side Thread Tee Fitting PED1004 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum capability to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a temperature range of -20 to +70 C. This SKU joins Dia 10 soft nylon or polyurethane tube on both inline ends to a 1/2in PT male thread (thread code 04), with a PBT body and a brass, pre-sealed stud.
On the PED run tee the two tube ports are in a straight line and only the threaded branch leaves at 90 degrees, so the main tube keeps running straight past the take-off. On the PEB branch tee, both tube ends leave perpendicular to the thread. Choose PED when the primary run must pass through and you just need a branch off it; choose PEB when the thread is the stem and two legs must turn away from it.
