Airtac PHW F Thread Swivel Tee Fitting PHW1004
The AirTAC Airtac PHW F Thread Swivel Tee Fitting PHW1004 is a genuine double universal male elbow for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeDouble universal male elbow
- SeriesPHW
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PHW F Thread Swivel Tee Fitting PHW1004
The AirTAC PHW1004 is a double universal male elbow in the resin one-touch range. It joins Dia 10 mm soft nylon or polyurethane tube to a 1/2 in PT male thread, and its double universal joint lets you set the outlet angle after installation instead of having to bend or twist the tubing into position.
To make the connection, push the tube straight into the chuck until it bottoms out - the stainless spring gasket and POM chuck grip the OD and seal it. Pressing the release ring frees the tube again for rework. This is the resin spec profile, not the metal BP line: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg (10 Torr), proof pressure 1.5 MPa, and a service temperature of -20 to +70 C. The 1/2 in stud ships with sealant already on the thread, and the body is grey PBT with a brass stud as standard; order PHW1004D for the black version.
Airtac PHW F Thread Swivel Tee Fitting PHW1004 Technical Specifications
| Model | Airtac PHW F Thread Swivel Tee Fitting PHW1004 |
|---|---|
| Type | Double universal male elbow |
| Series | PHW |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PHW F Thread Swivel Tee Fitting PHW1004
| PHW | Double universal male elbow. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PHW F Thread Swivel Tee Fitting PHW1004 Is Used
Pneumatic valve manifold outlet
The 1/2 in PT male thread lands directly on the outlet port of an air preparation or directional valve manifold, and the universal joint lets the Dia 10 tube leave at whatever angle the cabinet layout demands.
Packaging machine cylinder port
On carton-sealing and case-packing machines, large-bore push cylinders sit behind guards where a rigid elbow would fight the tube. The PHW1004 swivels to line the Dia 10 feed up with the run.
Conveyor air-blow cleaning jets
Belt-cleaning and product-blowoff nozzles on conveyor lines are often aimed at an angle; a double universal elbow lets the technician dial in the Dia 10 supply line direction without re-piping the port.
Is the Airtac PHW F Thread Swivel Tee Fitting PHW1004 the Right Part?
On the 1/2 in thread, PHW is offered in exactly three tube bores: Dia 8 (PHW804), this Dia 10 part, and Dia 12 (PHW1204). Stepping down to Dia 8 buys a slimmer profile for lighter circuits such as pilot air; stepping up to Dia 12 lowers resistance on high-consumption actuators. There is no M5 option anywhere in the PHW series, so small-bore instrument lines should look at PH or PHF instead. Whatever you pick, the tube OD must match the fitting exactly - a Dia 10 chuck will not seal on 3/8 in or 12 mm tube.
Match the 1/2 in thread to the port size, not to habit: many medium cylinders and valve manifolds with a 1/2 in port genuinely need it, but stepping the whole circuit up to 1/2 in fittings adds cost without flow benefit if the tubing is only Dia 8. If you need the same angle-flexibility at a panel wall, a bulkhead union is the wrong shape here - PHW is purely a threaded male elbow.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PHW F Thread Swivel Tee Fitting PHW1004 FAQ
This is a resin one-touch double universal male elbow with a Dia 10 mm tube connection and a 1/2 in PT male thread. Working pressure is 0-1.0 MPa (0-10 kgf/cm2), it handles vacuum down to -750 mmHg (10 Torr), proof pressure is 1.5 MPa, and the temperature range is -20 to +70 C. It takes soft nylon or polyurethane tube only. The body is grey PBT with a brass stud; PHW1004D gives the black colour option.
No - the chuck and seal are sized for one tube OD, so it holds Dia 10 mm tube only and will not seal on 12 mm or on 3/8 in imperial tube. If your run is Dia 8, order PHW804; if it is Dia 12, order PHW1204. Those are the only two neighbours on the 1/2 in thread, since AirTAC lists PHW in 1/2 in for 8, 10 and 12 mm tube and offers no M5 version of this series at all.
