Airtac PHW F Thread Swivel Tee Fitting PHW1004-S
SUS304 stainless variant (-S)The AirTAC Airtac PHW F Thread Swivel Tee Fitting PHW1004-S is a genuine double universal male elbow for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeDouble universal male elbow
- SeriesPHW
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PHW F Thread Swivel Tee Fitting PHW1004-S
The PHW1004-S is AirTAC's double universal male elbow in the resin one-touch range, sized for 10mm OD soft nylon or polyurethane tube on a 1/2in PT male thread. Unlike a fixed elbow, it carries two swivelling joints, so the body can rotate at both ends and the tube can enter at whatever angle the machine demands.
Installation is the standard one-touch action: push the 10mm tube into the chuck until it bottoms, and the stainless spring gasket and POM chuck grip it under a NBR O-ring seal; press the release ring to free it. On the -S variant, the male STUD is SUS304 while the body remains PBT - so you get a corrosion-resistant thread engagement on a 1/2in port without a solid-stainless price. It shares the resin spec profile: 0-1.0 MPa working pressure, 1.5 MPa proof, -20 to +70 C. The 1/2in PT thread arrives with sealant pre-applied.
Airtac PHW F Thread Swivel Tee Fitting PHW1004-S Technical Specifications
| Model | Airtac PHW F Thread Swivel Tee Fitting PHW1004-S |
|---|---|
| Type | Double universal male elbow |
| Series | PHW |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PHW F Thread Swivel Tee Fitting PHW1004-S
| PHW | Double universal male elbow. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PHW F Thread Swivel Tee Fitting PHW1004-S Is Used
Rotary indexing table air feed
The twin swivel joints let the 10mm feed line follow a rotating index plate through part of a revolution without kinking, landing on a fixed 1/2in PT manifold port.
Plating line jig-lift cylinder
Acid mist attacks brass threads inside a plating tank hood; the SUS304 stud on the 1/2in port and PBT body keep the connection serviceable in the splash zone.
Bottling line rinse-cage actuator
A double-swivel elbow routes the 10mm drop to a rotary actuator inside a wash-down guard, where a rigid elbow would fight the guard geometry and stress the tube.
Is the Airtac PHW F Thread Swivel Tee Fitting PHW1004-S the Right Part?
On the 1/2in thread, PHW exists in Dia 8, Dia 10 and Dia 12. Stepping down to PHW804-S lightens the loop for smaller actuators and lets you run narrower tube through tight ducts; stepping up to PHW1204-S raises flow headroom for longer 12mm runs or higher-demand cylinders. If your port is smaller than 1/2in, the same 10mm tube is also offered on 3/8in (PHW1003-S) - match the thread to the port, not the tube.
Tube OD must match exactly: this fitting will not hold 3/8in (10mm is not 3/8in NPT nominal) or any imperial tube. Note that PHW is not offered in M5 at all, so there is no miniature branch of this shape to fall back on.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PHW F Thread Swivel Tee Fitting PHW1004-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. It takes 10mm OD soft nylon or polyurethane tube and carries a 1/2in PT male thread with a SUS304 stud. Ratings are identical to the standard PHW1004 - the -S changes the stud material only.
No. On PHW, AirTAC's -S option makes the male stud SUS304; the elbow body stays PBT with a POM release button and aluminium-alloy guide. Pressure, temperature and dimensions are unchanged from the standard part. If you need every wetted and external surface non-metallic-plus-stainless, check the line's other elbows rather than assuming a solid stainless body.
