Airtac SCT80~100 Multi-Position Tandem Cylinder SCT80X100X0
2. Features specialized bidirectional sealing profile for pistons with compact dimensions and oil reservoir integration;
3. Tie-rod structure with pillar-connected end caps and aluminum alloy barrel ensures superior reliability;
4. Enables multi-position rod locking throughout the full stroke range;
5. Precision-adjustable pneumatic cushioning for smooth operation;
6. Configurable with multiple bore sizes and mounting accessories;
7. High-temperature resistant seals support operational range of 0-150°C.
Category: Multi-Position Force Amplifying Cylinders | Brand: AirTAC | Series: SCT80~100
AirTAC SCT80X100X0 Multi-Position Tandem Cylinder Specifications
- Model: SCT80X100X0
- Type: Double-acting multi-stage tandem cylinder
- Bore size: 80mm (3.15")
- Stroke: 100mm (3.94")
- Working pressure: 0.05–1.0 MPa (7–145 PSI)
- Piston rod diameter: 25mm (0.98")
- Port size: G1/2 (BSPP thread)
- Max thrust: 4900N @ 0.63MPa (single stage)
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Seal material: Polyurethane (NBR optional)
- Body material: Aluminum alloy (hard anodized)
- Weight: 6.8kg (14.99 lbs)
- Dimensions: 350mm(L) × 105mm(W) × 105mm(H)
- Mounting: Standard ISO 15552 (pre-drilled mounting holes)
- Accessories: Built-in magnet for position sensing (SM series switches compatible)
High-force compact cylinder combining multiple pistons in series configuration, delivering up to 3x standard cylinder force in same bore size. Features progressive force output with position-dependent pressure staging. Corrosion-resistant construction with precision ground rod for industrial environments.
- High-pressure clamping in injection molding machines
- Vertical press operations in automotive assembly
- Heavy workpiece positioning in CNC fixtures
- Elevation mechanisms for material handling systems
- Compact punching/stamping equipment
Installation note:
Requires staggered port alignment (180° rotation between stages).
Always use filtered air (≤40μm) with ISO VG32 lubricant.
Max side load tolerance: 150N. Install guide rods when lateral forces exceed 50N.
| Property | Property Value |
|---|---|
| sku | SCT80X100X0 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
| Stroke | 0mm |
