Airtac TSAIL Guided Cylinder TSAIL100X300S
$846.56
Regular price
$854.06
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X300S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation notes:
1. Maintain parallel alignment within 0.2mm/m between guide rails and load path
2. Use M12x1.25 mounting bolts (grade 8.8 or higher) with 35-40N·m torque
3. Lubricate guide rails with ISO VG32 hydraulic oil during initial installation
4. Allow 50mm clearance behind cylinder for magnetic sensor adjustment
Critical parameters:
- Maximum side load: 2,200N (static)/1,800N (dynamic)
- Maximum speed: 800mm/s (with cushion adjustment)
- Recommended cycle rate: ≤15 cycles/minute (full stroke)
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X300S Guided Rod Cylinder Specifications
- Model: TSAIL100X300S
- Type: Double-acting guided rod cylinder with precision linear bearings
- Bore size: Ø100mm
- Stroke: 300mm (±0.5mm tolerance)
- Mounting style: Side flange (ISO 15552 standard)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR/PU combination
- Port size: G1/2 (BSPP thread)
- Piston rod material: Hard chrome-plated 45# steel
- Guide rail type: Dual-axis hardened steel with PTFE coating
- Weight: 8.5kg (dry, without accessories)
- Dimensions:
- Total length (extended): 655±2mm
- Body width: 200mm (guide rail section)
- Height: 200mm (including mounting flange)
- Centerline height: 150mm (from base to rod axis)
High-rigidity guided cylinder featuring dual-axis linear bearings for exceptional moment load resistance (Rated moment: 850N·m). The TSAIL series combines traditional pneumatic actuation with mechanical guidance, eliminating rotation during stroke movement. Includes magnetic piston for sensor mounting (inductive sensors sold separately).
Typical Applications:
- Precision vertical lifting systems in automotive assembly
- Palletizing robot end-effector guidance
- Glass panel handling with vacuum grippers
- Press-fit operations requiring anti-rotation stability
- CNC machine tool auxiliary axis positioning
Installation notes:1. Maintain parallel alignment within 0.2mm/m between guide rails and load path
2. Use M12x1.25 mounting bolts (grade 8.8 or higher) with 35-40N·m torque
3. Lubricate guide rails with ISO VG32 hydraulic oil during initial installation
4. Allow 50mm clearance behind cylinder for magnetic sensor adjustment
Critical parameters:- Maximum side load: 2,200N (static)/1,800N (dynamic)
- Maximum speed: 800mm/s (with cushion adjustment)
- Recommended cycle rate: ≤15 cycles/minute (full stroke)
| Property | Property Value |
|---|---|
| sku | TSAIL100X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 300mm |
| Bearing Category | Linear Bearing |
