Airtac TSAIL Guided Cylinder TSAIL100X400
$880.52
Regular price
$888.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL100X400
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation requirements:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Maintain 0.3mm minimum clearance between guide rails and adjacent components.
Always verify rail parallelism (max 0.15mm/m tolerance) during mounting.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Rod Cylinder TSAIL100X400 Technical Details
- Model: TSAIL100X400
- Bore size: Ø100 mm
- Stroke: 400 mm
- Mounting type: Front/Rear flange (MF1/MF2 options)
- Operating pressure: 0.05–0.8 MPa
- Cushion type: Adjustable air cushion (both ends)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: G1/2 (BSPP thread)
- Guide mechanism: Dual linear rails with 4 ball bushings
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Max lateral load: 5,500 N
- Repeat positioning accuracy: ±0.1 mm
- Weight: 12.5 kg (excluding accessories)
- Dimensions: 940mm(L) × 150mm(W) × 200mm(H)
Heavy-duty guided cylinder engineered for precision linear motion under high moment loads. The dual rail guidance system eliminates rotational movement, making it ideal for vertical applications requiring strict positional accuracy. Features integrated wear indicators on guide bushings and optional stroke adjustment mechanism.
Industrial Applications:
- Automotive welding fixture positioning
- Die casting machine ejector systems
- Palletizing robot Z-axis actuation
- Press tool alignment mechanisms
- Heavy material transfer gates
Installation requirements:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Maintain 0.3mm minimum clearance between guide rails and adjacent components.
Always verify rail parallelism (max 0.15mm/m tolerance) during mounting.
WARNING: Not suitable for side-mounted load applications exceeding 30% of max moment capacity.
Use shock absorbers when cycle rate exceeds 60 strokes/minute.
| Property | Property Value |
|---|---|
| sku | TSAIL100X400 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <400mm> |
| Bearing Category | Linear Bearing |
