Airtac TSAIL Guided Cylinder TSAIL100X50S
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL100X50S Guided Rod Cylinder Specifications
- Model: TSAIL100X50S
- Type: Double-acting guided rod cylinder
- Bore size: 100mm
- Stroke: 50mm
- Mounting style: Square base with through holes
- Operating pressure: 0.1-1.0 MPa (14.5-145 psi)
- Temperature range: -20℃ to 80℃ (-4℉ to 176℉)
- Cushioning: Adjustable hydraulic buffer
- Port size: G3/8 (NPT1/4 optional)
- Guide mechanism: Dual rail precision linear guides
- Rod material: Chrome-plated steel (C45E)
- Cylinder body: Aluminum alloy with hard anodized finish
- Seals: NBR (Nitrile) standard, optional FKM/Viton
- Protection rating: IP54 (standard wiper)
- Weight: 12.5kg (27.56 lbs)
- Dimensions: 400mm(L) × 160mm(W) × 160mm(H)
High-rigidity guided cylinder designed for applications requiring precise linear motion with heavy side loads. Features integrated dual linear guides providing ≤0.05mm lateral play and 3x higher moment resistance compared to standard cylinders. The T-shaped guide block enables stable vertical/horizontal mounting with 4-point load distribution.
- Precision press brake tool positioning systems
- Automated material transfer arms in foundries
- Glass cutting machine Z-axis actuators
- Die-casting mold clamping mechanisms
- Semiconductor wafer handling robots
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Apply lithium soap-based grease
to guide rails every 500km of travel. Avoid continuous side load exceeding 2,500N.
For vertical mounting, install air exhaust ports upward.
| Property | Property Value |
|---|---|
| sku | TSAIL100X50S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <50mm> |
| Bearing Category | Linear Bearing |
