Airtac TSAIL Guided Cylinder TSAIL32X150S
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL Series Guided Cylinder TSAIL32X150S Technical Details
- Model Code: TSAIL32X150S
- Bore Size: 32mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating Pressure: 0.05-1.0 MPa
- Cushion Type: Adjustable rubber buffer (both ends)
- Mounting Style: MF1 (standard front flange)
- Guide Mechanism: Integrated dual linear ball bearings
- Rod Thread: M14×1.5 (external)
- Port Size: G1/8 (NPT1/8 optional)
- Seal Material: Polyurethane (NBR seals optional)
- Temperature Range: -20℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 compatible)
- Protection Class: IP54 (standard), IP67 with optional wipers
- Weight: 2.85kg (with guide bracket)
- Dimensions:
- Total Length (L): 305mm
- Body Width (W): 52mm
- Height with Guide (H): 88mm
- Guide Rail Span: 40mm
Precision double-acting cylinder with integrated rigid guide frame, designed for applications requiring high moment resistance and straight-line accuracy. Features chrome-plated piston rod (hardness HRC45-50) and anodized aluminum body. The dual linear bearings provide ±0.05mm repeat positioning accuracy under lateral loads up to 250N. Includes anti-rotation keyway and mounting surface flatness within 0.1mm.
- Precision fixturing in CNC machining centers
- Vertical lifting mechanisms in semiconductor handlers
- Pallet clamping in automated assembly lines
- Glass panel transfer systems
- Precision coating/deposition equipment
Installation Guidelines:
Maintain parallel alignment within 0.2mm/m between guide rails. Use Class 12.9 mounting screws torqued to 35N·m.
For vertical mounting, install air exhaust upward. Lubricate guide rails every 500km travel distance.
| Property | Property Value |
|---|---|
| sku | TSAIL32X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <32 mm> |
| Stroke | 150mm |
| Bearing Category | Linear Bearing |
