Airtac TSAIL Guided Cylinder TSAIL32X200S
$254.00
Regular price
$261.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TSAIL32X200S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The TSAIL Guide Rod Cylinder combines a precision-engineered guide frame with a pneumatic cylinder, delivering enhanced performance for industrial automation. Key features include:
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
Installation tip:
Align guide rail parallel to motion axis within 0.2mm/m tolerance.
Apply lithium soap-based grease to guide blocks every 500km of travel.
Critical note:
Do NOT use as vertical support structure - always employ mechanical stops.
Maximum side load decreases by 30% at full extension.
1. Dual bearing options:
- Slide bearings for high radial load capacity and superior torsional rigidity, ideal for braking applications requiring lateral stability.
- Linear bearings optimized for precision lifting operations, high-load scenarios, and low-friction movement requirements.
2. Multi-axis mounting system: The reinforced guide frame structure supports flexible installation configurations across multiple planes.
3. Advanced motion control: Features an adjustable cushioning mechanism for smooth stroke termination and vibration reduction.
4. Smart sensing integration: Equipped with adjustable sensor mounting brackets enabling customizable positioning for proximity detection systems.
Category: Guide Rod Cylinders | Brand: AIRTAC | Series: TSAIL
AirTAC TSAIL32X200S Guided Rod Cylinder Specifications
- Model: TSAIL32X200S
- Type: Double-acting guided cylinder with slide unit
- Bore size: 32mm
- Stroke: 200mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable rubber bumper (both ends)
- Guide mechanism: Dual linear ball bearings
- Mounting style: Horizontal base mounting (standard)
- Port size: M5x0.8 (1/8")
- Temperature range: -10℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU combination
- Weight: 2.85kg ±3%
- Dimensions:
- Total length (L): 356mm (at full extension)
- Body width (W): 64mm
- Height with guide (H): 72mm
- Mounting base: 45mm × 45mm
Precision guided cylinder featuring integrated linear motion guidance with ±0.05mm repeatability. The dual ball bearing slide unit eliminates rotational torque while maintaining 15kN lateral load capacity. Includes wear-resistant scraper seals and IP54 protection rating. Requires 40μm filtered lubricated air (ISO 8573-1).
Industrial Applications:
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for glass panel handling
- PCB depaneling machines requiring vibration-free motion
- Automated packaging line product orientation systems
- Medical device assembly with cleanroom compatibility
Installation tip:
Align guide rail parallel to motion axis within 0.2mm/m tolerance.
Apply lithium soap-based grease to guide blocks every 500km of travel.
Critical note:
Do NOT use as vertical support structure - always employ mechanical stops.
Maximum side load decreases by 30% at full extension.
| Property | Property Value |
|---|---|
| sku | TSAIL32X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <32 mm> |
| Stroke | <200mm> |
| Bearing Category | Linear Bearing |
