Airtac TSAIM Cylinder with Guide Bracket TSAIM100X150
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X150 Guided Cylinder Unit Specifications
- Model: TSAIM100X150
- Bore size: 100mm
- Stroke: 150mm
- Operating pressure: 0.1-0.8 MPa (ISO standard)
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Guide mechanism: Dual linear ball bearings with preload adjustment
- Rod material: Hard chrome-plated steel rod (Cr-Mo steel)
- Guide rail material: Anodized aluminum alloy with hardened steel shafts
- Mounting options: Front flange (MF1), rear flange (MF2), side-mount brackets
- Seal material: NBR (standard), optional Polyurethane for high-speed applications
- Temperature range: -20℃ to 80℃
- Max lateral load capacity: 3,500N
- Position detection: Magnetic sensor slots (SMCR series compatible)
- Weight: 8.5kg (±2%)
- Dimensions: 450mm(L) × 180mm(W) × 160mm(H)
- Protection rating: IP65 (standard wiper seal)
Heavy-duty guided cylinder with integrated linear motion system, combining pneumatic actuation and precision guidance. Features anti-rotation design with dual-axis reinforcement, ideal for vertical mounting applications requiring high moment resistance. Requires filtered air (5-50μm) with ISO 8573-1:2010 Class 3.2.4 standards.
- Automated palletizing systems with side load compensation
- Precision glass panel handling in LCD manufacturing
- Die-casting machine ejection mechanisms
- Automotive welding fixture positioning
- High-cycle packaging equipment with lateral stability requirements
Installation guidelines:
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
Align mounting surface within 0.2mm/m flatness tolerance.
For vertical installations exceeding 45° angle, use auxiliary support brackets (ASB-100 kit recommended).
| Property | Property Value |
|---|---|
| sku | TSAIM100X150 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
