Airtac TSAIM Cylinder with Guide Bracket TSAIM100X200
1. The TSAIM series represents an innovative integration of a guide frame and cylinder, delivering enhanced structural stability and functional versatility.
2. Bearing options optimized for diverse applications:
- Slide bearings: Engineered for radial load resistance in braking scenarios, offering superior torsional rigidity.
- Linear bearings: Ideal for pushing/lifting operations requiring high precision, heavy load capacity, and minimal friction applications.
3. Multi-axis mounting configurations enabled by the guide frame's proprietary design, ensuring flexible installation adaptability.
4. Precision cushioning adjustment system guarantees smooth stroke termination and operational stability.
5. Modular sensor mounting base allows positional customization to meet diverse sensing requirements.
Category: Guide Rod Cylinders | Brand: AirTAC | Series: TSAIM
AirTAC TSAIM100X200 Guided Cylinder Specifications
- Model: TSAIM100X200
- Type: Double-acting guided cylinder with integrated linear guides
- Bore size: 100mm
- Stroke: 200mm (customizable 25-2000mm)
- Operating pressure: 0.1-0.9 MPa
- Piston speed: 50-1000 mm/s
- Guide mechanism: Dual linear ball bearings
- Rod material: Hard chrome-plated steel (S45C)
- Cylinder tube: Aluminum alloy (AL6063-T5)
- Seal material: NBR + PU combination
- Mounting options: Front flange (MF1), rear flange (MF2), side-mount (MS1)
- Cushioning: Adjustable hydraulic shock absorber
- Temperature range: -20℃ to 80℃
- Weight: 15.8 kg (without accessories)
- Dimensions: 400mm(L) × 200mm(W) × 200mm(H) (stroke-dependent)
- Load capacity: 2000N radial / 1500N lateral
- Repeat positioning accuracy: ±0.05mm
- ISO standard: 15552
Industrial-grade guided cylinder featuring dual-axis linear ball guides for exceptional moment resistance and precision alignment. The T-shaped guide block design minimizes deflection under heavy side loads. Includes wear-resistant scraper seals and auto-lubrication grooves. Compatible with magnetic sensors (D-M9N series) for position feedback.
- Precision press-fit operations in automotive assembly
- Vertical lifting systems with lateral stability requirements
- Palletizing robots requiring anti-rotation control
- High-precision CNC fixture positioning
- Glass panel handling systems with tilt prevention
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Apply lithium soap-based grease
(ISO-LB grade) to guide rails every 500km of travel. Avoid simultaneous lateral
and radial loading beyond 80% of rated capacity.
| Property | Property Value |
|---|---|
| sku | TSAIM100X200 |
| Port Size | PT 1/2 |
| Bore Diameter | 100mm |
